Special Trucks
SHACMAN M3000 Concrete Mixer Truck 300 / 340 / 375 / 380HP 8 / 10 / 12 / 14CBM Available
SHACMAN M3000 Concrete Mixer Truck is a medium- and heavy-duty construction vehicle designed for transporting ready-mixed concrete from batching plants to construction sites while continuously agitating the concrete during transportation. The vehicle combines the SHACMAN M3000 chassis with a high-strength concrete mixing drum, hydraulic drive system, hydraulic pump, hydraulic motor, reducer, feeding hopper, discharge chute, water system and reinforced mixer subframe. The SHACMAN M3000 platform is part of SHACMAN's international heavy-truck product family and is available for special-purpose vehicle applications. Common mixer configurations can be equipped with Weichai or Cummins diesel engines, FAST manual transmissions and heavy-duty drive axles. 300HP, 340HP, 375HP and 380HP power configurations are suitable for different concrete loads, road conditions and operating requirements. The M3000 concrete mixer can be configured with 6×4 or 8×4 chassis layouts and approximately 8CBM, 10CBM, 12CBM and 14CBM mixer capacities. The high-strength mixer drum uses internal spiral mixing blades to maintain concrete uniformity during transportation, while the hydrostatic hydraulic drive system provides smooth drum rotation for feeding, mixing and discharge operations.
- Tel+86 139 6411 3362
- WhatsApp+86 139 6411 3362
- Emailluisa@sdlvnengintel.com
Product Description
Product Specifications
| Item | Specification Range |
|---|---|
| Product Type | Concrete Mixer Truck / Cement Mixer Truck / Transit Mixer Truck |
| Brand | SHACMAN |
| Model Series | M3000 / Delong M3000 |
| Drive Type | 6×4 / 8×4 available |
| Engine Power | 300HP / 340HP / 375HP / 380HP available according to chassis and stock |
| Engine Brand | Weichai / Cummins |
| Common Engine Series | WP10 / WP12 / Cummins series or equivalent |
| Engine Type | Inline six-cylinder, turbocharged and intercooled diesel engine |
| Engine Displacement | Approx. 9.7–11.6 L depending on engine configuration |
| Maximum Torque | Approx. 1,250–1,800 N·m depending on engine configuration |
| Fuel Type | Diesel |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V available according to model year and export market |
| Transmission Brand | FAST |
| Transmission Type | Manual transmission |
| Transmission Gears | 9-speed / 10-speed / 12-speed manual transmission available |
| Common Transmission | FAST 9JS / 10JS / 12JS series or equivalent |
| Clutch | Heavy-duty dry single-plate clutch |
| PTO | Heavy-duty power take-off for mixer hydraulic system |
| Cab Series | SHACMAN M3000 |
| Cab Type | Standard / extended cab according to chassis |
| Seating Capacity | 2 persons commonly available |
| Sleeper | Single sleeper available according to cab configuration |
| Driver Seat | Adjustable / air-suspension driver seat optional |
| Steering | Left-hand drive or right-hand drive optional |
| Power Steering | Hydraulic power steering |
| Air Conditioner | Available / optional according to stock |
| Overall Length | Approx. 8,500–11,000 mm |
| Overall Width | Approx. 2,500–2,550 mm |
| Overall Height | Approx. 3,700–4,000 mm |
| Wheelbase | Multiple wheelbase configurations available for 6×4 / 8×4 chassis |
| Gross Vehicle Weight | Approx. 25–35 tons depending on chassis and mixer configuration |
| Curb Weight | Approx. 11–16 tons depending on chassis and mixer body |
| Maximum Driving Speed | Approx. 80–100 km/h |
| Front Axle | SHACMAN / MAN technology steering axle |
| Front Axle Capacity | Approx. 7.5–9.5 tons depending on chassis |
| Rear Axle | SHACMAN / MAN technology heavy-duty drive axle |
| Rear Axle Capacity | Approx. 13–16 tons per drive axle depending on configuration |
| Rear Axle Type | Single-reduction / hub-reduction drive axle available |
| Rear Axle Ratio | Multiple axle ratios available according to working conditions |
| Differential Lock | Available according to axle configuration |
| Frame | Reinforced high-strength steel chassis frame |
| Subframe | Reinforced concrete-mixer subframe |
| Front Suspension | Multi-leaf spring suspension |
| Rear Suspension | Reinforced multi-leaf spring / bogie suspension |
| Tire Model | 11.00R20 / 12.00R20 / 315/80R22.5 or equivalent |
| Tire Quantity | According to 6×4 / 8×4 chassis; spare tire available |
| Fuel Tank | Approx. 300–500 L |
| Fuel Tank Material | Aluminum / steel optional |
| Brake System | Dual-circuit compressed-air brake system |
| Parking Brake | Spring-energy compressed-air brake |
| Auxiliary Brake | Engine exhaust brake available |
| ABS | Available according to chassis |
| Electrical System | 24V |
| Mixer Body Type | Rotating concrete mixing drum |
| Effective Mixer Capacity | 8CBM / 10CBM / 12CBM / 14CBM available |
| Mixer Drum Material | High-strength wear-resistant steel |
| Drum Structure | Reinforced drum with internal double-helical mixing blades |
| Drum Rotation | Forward / reverse rotation |
| Drum Rotation Speed | Approx. 0–16 rpm depending on hydraulic system |
| Mixing Blade Type | Double-helical / spiral mixing blades |
| Mixing Blade Material | High-strength wear-resistant steel |
| Hydraulic Drive Type | Hydrostatic hydraulic drive system |
| Hydraulic Pump | Rexroth / EATON / PMP or equivalent optional |
| Hydraulic Motor | Rexroth / EATON / PMP or equivalent optional |
| Reducer | Bonfiglioli / ZF / PMP or equivalent mixer reducer optional |
| Hydraulic Oil Tank | Available |
| Hydraulic Oil Cooler | Available / optional |
| Feeding System | Rear feeding hopper |
| Feeding Hopper | Reinforced large-capacity feeding hopper |
| Feeding Hopper Material | High-strength steel with wear-resistant lining optional |
| Feeding Speed | Approx. ≥3 m³/min depending on mixer configuration |
| Discharge System | Rear discharge chute |
| Discharge Speed | Approx. 2–3 m³/min depending on mixer configuration and concrete condition |
| Main Discharge Chute | Adjustable and rotatable discharge chute |
| Extension Chute | One or more extension chutes optional |
| Concrete Residual Rate | Low-residual drum and blade design |
| Water Tank Capacity | Approx. 300–500 L |
| Water Tank Material | Steel / aluminum optional |
| Water Supply System | Pressurized / gravity water supply system |
| Drum Cleaning System | Integrated water flushing system |
| Hopper Cleaning | Available |
| Chute Cleaning | Available |
| Hand-Washing Outlet | Optional |
| Rear Operating Control | Mechanical / electro-hydraulic control |
| Drum Speed Control | Adjustable |
| Drum Direction Control | Mixing / neutral / discharge |
| Cab Drum Control | Optional |
| Support Roller | Heavy-duty mixer drum support rollers |
| Drum Support Structure | Reinforced front and rear mixer drum supports |
| Rear Ladder | Available |
| Rear Fender | Available |
| Reversing Camera | Optional |
| Rear Working Camera | Optional |
| 360° Monitoring System | Optional |
| Working Lights | Optional |
| Warning Lamp | Optional |
| Toolbox | Available / optional |
| Fire Extinguisher | Available / optional |
| Color | White, red, blue, green, yellow or customized |
| Condition | Used / Refurbished / Customized according to stock |
| Customization | Engine, transmission, drive type, mixer capacity, mixer drum material, hydraulic pump, hydraulic motor, reducer, water system, axle ratio, tires, steering side, paint color, company logo and export markings |
Product Details
Typical Applications
- Ready-mixed concrete transportation
- commercial concrete batching plants
- residential building construction
- commercial building construction
- industrial plant construction
- urban road construction
- highway construction
- bridge construction
- tunnel construction
- railway projects
- airport construction
- port construction
- municipal infrastructure
- hydropower projects
- industrial park development
- foundation construction
- mining infrastructure
- precast concrete projects
- dam construction
- large-scale infrastructure projects
- urban development projects
- construction contractor fleet operations.
Available Configurations
- 300HP, 340HP, 375HP or 380HP diesel engine
- Weichai WP10, WP12, Cummins or equivalent engine
- 6×4 or 8×4 drive configuration
- left-hand drive or right-hand drive
- Euro II / Euro III / Euro IV / Euro V emission configuration according to model year and export market
- FAST 9-speed, 10-speed or 12-speed manual transmission
- 8CBM, 10CBM, 12CBM or 14CBM effective mixer capacity
- high-strength wear-resistant mixer drum
- reinforced double-helical mixing blades
- Rexroth, EATON, PMP or equivalent hydraulic pump
- Rexroth, EATON, PMP or equivalent hydraulic motor
- Bonfiglioli, ZF, PMP or equivalent mixer reducer
- hydraulic oil cooling system
- approximately 300–500L water tank
- pressurized water system
- reinforced feeding hopper
- wear-resistant hopper lining
- adjustable discharge chute
- extension discharge chute
- mechanical or electro-hydraulic rear controls
- cab-mounted drum control
- reversing camera
- rear working camera
- 360° monitoring system
- working lights
- warning lamps
- ABS
- air conditioner
- air-suspension driver seat
- different axle ratios and tire specifications
- spare tire
- toolbox
- fire extinguisher
- customized mixer capacity, hydraulic system, paint color, company logo and export markings.
Buyer Support
- SHACMAN M3000 Concrete Mixer Truck combines the practical M3000 heavy-duty chassis platform with a professional concrete mixing and transportation system for batching plants, construction contractors and infrastructure projects
- 300HP, 340HP, 375HP and 380HP engine options provide multiple power configurations for different concrete loads, road conditions and project requirements
- Weichai and Cummins engine options together with FAST manual transmissions provide a mature, durable and service-friendly powertrain for commercial operation. 6×4 and 8×4 chassis configurations provide flexibility for different mixer capacities and axle-load requirements
- 8CBM, 10CBM, 12CBM and 14CBM mixer options cover medium- and heavy-duty concrete transportation applications
- high-strength wear-resistant mixer drums and reinforced spiral blades provide continuous concrete agitation during transportation and efficient feeding and discharge at construction sites. The hydrostatic hydraulic drive system provides smooth and adjustable mixer-drum rotation, while Rexroth, EATON, PMP, Bonfiglioli, ZF and equivalent hydraulic components can be selected to meet different operating and maintenance requirements. The reinforced chassis frame, heavy-duty drive axles, multi-leaf spring suspension and dedicated mixer subframe provide stable support for continuous loaded operation
- approximately 300–500L water-system options support cleaning of the mixer drum, feeding hopper and discharge chute after unloading
- adjustable rear discharge chutes simplify concrete placement at construction sites
- left-hand-drive and right-hand-drive versions support different export markets
- engine, transmission, mixer capacity, hydraulic system, reducer, water system, axle ratio, tires, paint color and other configurations can be customized.
