SHACMAN H3000 Water Tanker Truck 300 / 336 / 340 / 375 / 380 / 400 / 430 / 460HP 10 / 15 / 20 / 25 / 30CBM Available – Water Sprinkler Optional
SHACMAN H3000 Water Tanker Truck is a medium- and heavy-duty water transportation vehicle designed for construction projects, mining operations, road engineering, municipal services, industrial facilities, agriculture and remote-area water supply. The vehicle combines a durable SHACMAN H3000 chassis with a reinforced large-capacity water tank, PTO-driven water pump, piping system, valves and filling/discharge equipment for reliable bulk-water transportation. The vehicle can be supplied as a pure water tanker for water loading, transportation and discharge, or equipped with an optional water sprinkler system for mine-road dust suppression, construction-site dust control, road watering, municipal cleaning and landscape irrigation. Customers can select the required sprinkler equipment according to the actual project without changing the basic tanker platform. SHACMAN H3000 supports 4×2, 6×4 and 8×4 chassis configurations, with Weichai or Cummins engines and a broad power range. SHACMAN lists H3000 configurations from approximately 270–460PS, while H3000 tank-truck configurations include 300HP, 336HP, 340HP, 375HP, 380HP, 400HP, 430HP and 460HP options. Water tank capacities of approximately 10–30CBM can be configured according to chassis, payload requirements and project conditions.
- Tel+86 139 6411 3362
- WhatsApp+86 139 6411 3362
- Emailluisa@sdlvnengintel.com
Product Description
Product Specifications
| Item | Specification Range |
|---|---|
| Product Type | Water Tanker Truck / Water Bowser Truck / Water Transport Truck / Water Sprinkler Truck |
| Brand | SHACMAN |
| Chassis Series | SHACMAN H3000 |
| Drive Type | 4×2 / 6×4 / 8×4 available |
| Engine Power | 300HP / 336HP / 340HP / 375HP / 380HP / 400HP / 430HP / 460HP available |
| Engine Brand | Weichai / Cummins |
| Engine Type | Inline six-cylinder turbocharged and intercooled diesel engine |
| Fuel Type | Diesel |
| Emission Standard | Euro II / Euro III / Euro V available according to chassis and export market |
| Transmission Brand | FAST / ZF depending on configuration |
| Transmission Type | Manual / AMT available according to chassis |
| Transmission Gears | 9-speed / 10-speed / 12-speed / 13-speed / 16-speed depending on configuration |
| PTO | Available for water-pump operation |
| Cab Series | SHACMAN H3000 |
| Cab Type | Standard narrow-body / extended flat-roof / extended high-roof cab |
| Seating Capacity | 2–3 persons |
| Sleeper | Available according to cab configuration |
| Driver Seat | Adjustable / air-suspension or hydraulic seat available |
| Steering | Left-hand drive / right-hand drive optional |
| Power Steering | Hydraulic power steering |
| Air Conditioner | Available |
| Overall Length | Approx. 7,500–12,000 mm depending on chassis and tank volume |
| Overall Width | Approx. 2,400–2,550 mm |
| Overall Height | Approx. 3,000–3,800 mm |
| Wheelbase | Multiple wheelbase configurations available according to 4×2 / 6×4 / 8×4 chassis |
| Gross Vehicle Weight | Approx. 18–50 tons depending on chassis configuration |
| Rated Payload | According to chassis, tank volume and local certification |
| Maximum Driving Speed | Approx. 80–100 km/h |
| Front Axle | SHACMAN / HANDE heavy-duty steering axle |
| Front Axle Capacity | Approx. 7.5–9.5 tons depending on chassis |
| Rear Axle | SHACMAN / HANDE heavy-duty drive axle |
| Rear Axle Capacity | Approx. 13–16 tons per axle depending on configuration |
| Rear Axle Type | Single-reduction / hub-reduction available |
| Differential Lock | Available |
| Frame | Reinforced high-strength steel chassis frame |
| Tank Subframe | Reinforced tanker special-purpose subframe |
| Front Suspension | Leaf spring suspension |
| Rear Suspension | Heavy-duty multi-leaf spring / balance suspension |
| Tire Model | 11.00R20 / 12.00R20 / 12R22.5 / 315/80R22.5 or equivalent |
| Tire Quantity | According to 4×2 / 6×4 / 8×4 chassis |
| Spare Tire | Available / optional |
| Fuel Tank | Approx. 300–600 L depending on chassis |
| Fuel Tank Material | Aluminum alloy / steel optional |
| Brake System | Dual-circuit compressed-air brake system |
| Parking Brake | Spring-energy compressed-air brake |
| Auxiliary Brake | Engine exhaust brake / engine brake available |
| ABS | Available |
| Electrical System | 24V |
| Tank Capacity | 10CBM / 15CBM / 20CBM / 25CBM / 30CBM available |
| Common 4×2 Tank Capacity | Approx. 10–15 CBM |
| Common 6×4 Tank Capacity | Approx. 15–25 CBM |
| Common 8×4 Tank Capacity | Approx. 20–30 CBM |
| Tank Shape | Elliptical / oval cylindrical tank |
| Tank Material | Q235 carbon steel / high-strength carbon steel / stainless steel optional |
| Carbon-Steel Tank | Available |
| Stainless-Steel Tank | Optional |
| Tank Body Thickness | Approx. 4–6 mm or customized |
| Tank Head Thickness | Approx. 5–7 mm or customized |
| Tank Compartments | Single compartment standard / multi-compartment optional |
| Internal Anti-Wave Baffles | Multiple internal anti-wave baffles |
| Baffle Function | Reduces liquid surge during acceleration, braking and cornering |
| Manhole | Available |
| Manhole Cover | Bolt-type / quick-opening type optional |
| Tank Ladder | Available |
| Top Walkway | Anti-slip walkway optional |
| Top Guardrail | Optional |
| Water Pump | Available |
| Pump Type | Self-priming centrifugal water pump |
| Pump Drive | PTO-driven |
| Pump Flow Rate | Approx. 40–80 m³/h depending on pump |
| Pump Head | Approx. 45–90 m depending on pump |
| Self-Priming Function | Available |
| Self-Suction Depth | Approx. 5–7 m depending on pump |
| Water Filling Method | Pump self-suction / external pressure filling |
| Water Discharge Method | Pump discharge / gravity discharge |
| Water Inlet | Available |
| Water Outlet | Available |
| Gravity Discharge Valve | Available |
| Suction Hose | Available / optional |
| Suction Hose Length | Approx. 5–8 m or customized |
| Pipeline Material | Carbon steel / galvanized steel / stainless steel optional |
| Valve Material | Carbon steel / aluminum alloy / stainless steel optional |
| Pure Water Tanker Configuration | Available |
| Water Sprinkler Configuration | Optional |
| Front Sprinkler | Optional |
| Rear Sprinkler | Optional |
| Side Sprinkler | Optional |
| Front Duckbill Nozzle | Optional |
| Rear Spray Nozzle | Optional |
| Sprinkling Width | Approx. 14–20 m depending on sprinkler configuration |
| Rear Water Cannon | Optional |
| Water Cannon Range | Approx. 25–35 m depending on pump and nozzle |
| Water Cannon Rotation | Adjustable |
| Water Cannon Spray Pattern | Column / heavy rain / moderate rain / mist adjustable |
| High-Pressure Water Cannon | Optional |
| Front Flushing System | Optional |
| Rear Flushing System | Optional |
| Side Spray System | Optional |
| Road Washing System | Optional |
| Mine-Road Dust Suppression | Optional |
| Construction-Site Dust Control | Optional |
| Municipal Road Sprinkling | Optional |
| Landscape Irrigation System | Optional |
| Green-Belt Watering | Optional |
| Hand Spray Gun | Optional |
| High-Pressure Spray Gun | Optional |
| Hose Reel | Optional |
| Fire Hose Connection | Optional |
| Fire-Fighting Interface | Optional |
| Water Level Gauge | Mechanical / electronic optional |
| Electronic Water-Level Indicator | Optional |
| Overflow Pipe | Available |
| Bottom Drain Valve | Available |
| Tank Cleaning Port | Available |
| Internal Anti-Corrosion Coating | Optional |
| External Anti-Corrosion Treatment | Primer + industrial topcoat |
| Stainless-Steel Inner Tank | Optional |
| Rear Working Platform | Optional |
| Pump Compartment | Optional |
| Hose Storage Box | Optional |
| Toolbox | Available / optional |
| Rear Working Lights | Optional |
| LED Warning Lights | Optional |
| Reversing Camera | Optional |
| Rear Working Camera | Optional |
| 360° Monitoring System | Optional |
| Fire Extinguisher | Available / optional |
| Color | White, blue, green, yellow, red, orange or customized |
| Condition | Used / Refurbished / Customized according to stock |
| Customization | Engine, drive type, tank capacity, tank material, tank thickness, water pump, pipeline system, sprinkler equipment, water cannon, filling/discharge system, steering side, cameras, warning equipment, paint color, company logo and export markings |
Product Details
Typical Applications
- Mining-site water transportation
- mine-road dust suppression
- quarry dust control
- construction-site water supply
- construction-site dust control
- road construction
- highway maintenance
- municipal water transportation
- urban road watering
- industrial water transportation
- factory water supply
- construction-camp water supply
- port and terminal water supply
- agricultural water transportation
- farm irrigation
- landscape irrigation
- green-belt watering
- road washing
- municipal sanitation
- rural water supply
- remote-area water delivery
- emergency water supply
- general bulk-water transportation.
Available Configurations
- 300HP, 336HP, 340HP, 375HP, 380HP, 400HP, 430HP or 460HP diesel engine
- SHACMAN H3000 4×2, 6×4 or 8×4 chassis
- Weichai or Cummins diesel engine
- left-hand drive or right-hand drive
- Euro II / Euro III / Euro V configuration according to chassis
- FAST or ZF transmission
- manual or AMT gearbox according to chassis
- 10CBM, 15CBM, 20CBM, 25CBM or 30CBM water tank
- Q235 carbon-steel, high-strength steel or stainless-steel tank
- customized tank-body and tank-head thickness
- single-compartment or multi-compartment tank
- multiple internal anti-wave baffles
- PTO-driven self-priming centrifugal water pump
- customized pump flow and pump head
- self-suction filling
- external pressure filling
- pump discharge
- gravity discharge
- pure water tanker configuration
- front sprinkler
- rear sprinkler
- side sprinkler
- duckbill nozzles
- rear water cannon
- high-pressure water cannon
- front and rear road-flushing system
- mine-road dust-suppression system
- construction-site sprinkler system
- municipal road sprinkler system
- landscape irrigation system
- hose reel
- hand spray gun
- fire-fighting connection
- mechanical or electronic water-level indicator
- stainless-steel valves and pipelines
- internal anti-corrosion coating
- rear working platform
- pump compartment
- hose storage box
- reversing camera
- rear working camera
- 360° monitoring system
- LED warning lights
- toolbox
- customized tank capacity, water system, paint color, company logo and export markings.
Buyer Support
- SHACMAN H3000 Water Tanker Truck combines the H3000 commercial chassis with a large-capacity water tank for construction, mining, municipal, industrial and agricultural applications. The H3000 platform supports 4×2, 6×4 and 8×4 configurations, Weichai or Cummins engines, and approximately 270–460PS across the broader chassis range, providing flexible solutions for different payload levels and working environments. The H3000 tank-truck chassis is available with multiple engine configurations including approximately 300HP, 336HP, 340HP, 375HP, 380HP, 400HP, 430HP and 460HP, making it suitable for medium- and heavy-duty water transportation. The vehicle can be supplied as a pure water tanker when the primary requirement is bulk-water loading, transportation and discharge. This configuration is suitable for construction camps, mining projects, factories, agricultural sites and remote areas where sprinkler equipment is not required. A complete water sprinkler system can also be added as an option. Front sprinklers, rear sprinklers, side sprays, duckbill nozzles, road-flushing equipment and rear water cannons can be configured for mine-road dust suppression, construction-site dust control, municipal watering and landscape irrigation. 10CBM, 15CBM, 20CBM, 25CBM and 30CBM tank configurations cover different water-transport requirements. Multiple internal anti-wave baffles reduce water surge during braking, acceleration and cornering, helping improve loaded vehicle stability. The PTO-driven self-priming centrifugal pump allows water to be drawn directly from ponds, reservoirs, storage tanks and other external sources. Pump discharge and gravity discharge provide flexible water-delivery methods for projects with limited fixed water infrastructure. Carbon-steel tanks provide a durable and economical solution for mining, construction and general industrial use, while stainless-steel tanks can be selected for applications requiring improved corrosion resistance or cleaner water-storage conditions. Left-hand-drive and right-hand-drive versions are available for different export markets. Engine power, drive configuration, tank volume, tank material, water pump, piping system, sprinkler equipment, water cannon, filling and discharge equipment, monitoring system, paint color and other specifications can be customized according to project requirements.
Product Display
