SHACMAN F3000 Water Tanker Truck 340 / 375 / 380 / 400 / 420HP 15 / 20 / 25 / 30CBM Available – Water Sprinkler Optional
SHACMAN F3000 Water Tanker Truck is a heavy-duty water transportation vehicle designed for mining operations, construction projects, road engineering, industrial facilities, municipal services, agriculture and remote-area water supply. The vehicle combines a durable SHACMAN F3000 chassis with a reinforced large-capacity water tank, PTO-driven water pump, piping system, valves and filling/discharge equipment for reliable bulk-water transportation under demanding working conditions. The vehicle can be supplied as a pure water tanker for water loading, transportation and discharge, or equipped with an optional water sprinkler system for mine-road dust suppression, construction-site dust control, road watering, municipal cleaning and landscape irrigation. Customers can select only the required sprinkler equipment according to actual operating conditions. SHACMAN F3000 water tanker trucks are mainly available with 6×4 and 8×4 heavy-duty chassis configurations. Engine options include approximately 340HP, 375HP, 380HP, 400HP and 420HP, while water tank capacities of approximately 15CBM, 20CBM, 25CBM and 30CBM can be configured according to chassis payload, road conditions and project requirements. Carbon-steel and stainless-steel tank options are available.
- Tel+86 139 6411 3362
- WhatsApp+86 139 6411 3362
- Emailluisa@sdlvnengintel.com
Product Description
Product Specifications
| Item | Specification Range |
|---|---|
| Product Type | Water Tanker Truck / Water Bowser Truck / Water Transport Truck / Water Sprinkler Truck |
| Brand | SHACMAN |
| Chassis Series | SHACMAN F3000 |
| Drive Type | 6×4 / 8×4 available |
| Engine Power | 340HP / 375HP / 380HP / 400HP / 420HP available according to chassis and stock |
| Engine Brand | Weichai / Cummins |
| Engine Type | Inline six-cylinder turbocharged and intercooled diesel engine |
| Fuel Type | Diesel |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V available according to chassis and export market |
| Transmission Brand | FAST |
| Transmission Type | Manual transmission |
| Transmission Gears | 10-speed / 12-speed available according to chassis |
| PTO | Available for water-pump operation |
| Cab Series | SHACMAN F3000 |
| Cab Type | Standard / extended heavy-duty cab |
| Seating Capacity | 2–3 persons |
| Sleeper | Available |
| Driver Seat | Adjustable / air-suspension seat available |
| Steering | Left-hand drive / right-hand drive optional |
| Power Steering | Hydraulic power steering |
| Air Conditioner | Available |
| Overall Length | Approx. 8,500–12,000 mm depending on chassis and tank capacity |
| Overall Width | Approx. 2,500–2,550 mm |
| Overall Height | Approx. 3,200–3,800 mm |
| Wheelbase | Multiple wheelbase configurations available for 6×4 / 8×4 chassis |
| Gross Vehicle Weight | Approx. 25–41 tons depending on chassis |
| Curb Weight | Approx. 11–18 tons depending on tank and equipment |
| Rated Payload | According to chassis, tank volume and local certification |
| Maximum Driving Speed | Approx. 80–95 km/h |
| Front Axle | SHACMAN / MAN technology steering axle |
| Rear Axle | SHACMAN / MAN technology heavy-duty drive axle |
| Rear Axle Type | Hub-reduction / single-reduction available |
| Differential Lock | Available |
| Frame | Reinforced high-strength heavy-duty chassis frame |
| Tank Subframe | Reinforced tanker special-purpose subframe |
| Front Suspension | Multi-leaf spring suspension |
| Rear Suspension | Heavy-duty multi-leaf spring / balance suspension |
| Tire Model | 12.00R20 / 12R22.5 / 315/80R22.5 or equivalent |
| Tire Quantity | According to 6×4 / 8×4 chassis |
| Spare Tire | Available / optional |
| Fuel Tank | Approx. 300–500 L |
| Fuel Tank Material | Steel / aluminum optional |
| Brake System | Dual-circuit compressed-air brake system |
| Parking Brake | Spring-energy compressed-air brake |
| Auxiliary Brake | Engine exhaust brake / engine brake available |
| ABS | Available |
| Electrical System | 24V |
| Tank Capacity | 15CBM / 20CBM / 25CBM / 30CBM available |
| Common 6×4 Tank Capacity | Approx. 15–25 CBM |
| Common 8×4 Tank Capacity | Approx. 20–30 CBM |
| Tank Shape | Elliptical / oval cylindrical tank |
| Tank Material | Q235 carbon steel / high-strength carbon steel / stainless steel optional |
| Carbon-Steel Tank | Available |
| Stainless-Steel Tank | Optional |
| Tank Body Thickness | Approx. 4–6 mm or customized |
| Tank Head Thickness | Approx. 5–7 mm or customized |
| Tank Compartments | Single compartment standard / multi-compartment optional |
| Internal Anti-Wave Baffles | Multiple internal anti-wave baffles |
| Baffle Function | Reduces liquid surge during acceleration, braking and cornering |
| Manhole | Available |
| Manhole Cover | Bolt-type / quick-opening type optional |
| Tank Ladder | Available |
| Top Walkway | Anti-slip walkway optional |
| Top Guardrail | Optional |
| Water Pump | Available |
| Pump Type | Self-priming centrifugal water pump |
| Pump Drive | PTO-driven |
| Pump Flow Rate | Approx. 40–80 m³/h depending on pump |
| Pump Head | Approx. 45–90 m depending on pump configuration |
| Self-Priming Function | Available |
| Self-Suction Depth | Approx. 5–7 m depending on pump |
| Water Filling Method | Pump self-suction / external pressure filling |
| Water Discharge Method | Pump discharge / gravity discharge |
| Water Inlet | Available |
| Water Outlet | Available |
| Gravity Discharge Valve | Available |
| Suction Hose | Available / optional |
| Suction Hose Length | Approx. 5–8 m or customized |
| Pipeline Material | Carbon steel / galvanized steel / stainless steel optional |
| Valve Material | Carbon steel / aluminum alloy / stainless steel optional |
| Pure Water Tanker Configuration | Available |
| Water Sprinkler Configuration | Optional |
| Front Sprinkler | Optional |
| Rear Sprinkler | Optional |
| Side Sprinkler | Optional |
| Front Duckbill Nozzle | Optional |
| Rear Spray Nozzle | Optional |
| Sprinkling Width | Approx. 14–20 m depending on sprinkler system |
| Rear Water Cannon | Optional |
| Water Cannon Range | Approx. 25–35 m depending on pump and nozzle |
| Water Cannon Rotation | Adjustable |
| Water Cannon Spray Pattern | Column / heavy rain / moderate rain / mist adjustable |
| High-Pressure Water Cannon | Optional |
| Front Flushing System | Optional |
| Rear Flushing System | Optional |
| Side Spray System | Optional |
| Road Washing System | Optional |
| Mine-Road Dust Suppression | Optional |
| Construction-Site Dust Control | Optional |
| Municipal Road Sprinkling | Optional |
| Landscape Irrigation System | Optional |
| Green-Belt Watering | Optional |
| High-Pressure Spray Gun | Optional |
| Hand Spray Gun | Optional |
| Hose Reel | Optional |
| Fire Hose Connection | Optional |
| Fire-Fighting Interface | Optional |
| Water Level Gauge | Mechanical / electronic optional |
| Electronic Water Level Indicator | Optional |
| Overflow Pipe | Available |
| Bottom Drain Valve | Available |
| Tank Cleaning Port | Available |
| Internal Anti-Corrosion Coating | Optional |
| External Anti-Corrosion Treatment | Primer + industrial topcoat |
| Stainless-Steel Inner Tank | Optional |
| Rear Working Platform | Optional |
| Pump Compartment | Optional |
| Hose Storage Box | Optional |
| Toolbox | Available / optional |
| Rear Working Lights | Optional |
| LED Warning Lights | Optional |
| Reversing Camera | Optional |
| Rear Working Camera | Optional |
| 360° Monitoring System | Optional |
| Fire Extinguisher | Available / optional |
| Color | White, blue, green, yellow, red, orange or customized |
| Condition | Used / Refurbished / Customized according to stock |
| Customization | Engine, drive type, tank capacity, tank material, tank thickness, water pump, pipelines, sprinkler equipment, water cannon, filling/discharge system, steering side, cameras, warning equipment, paint color, company logo and export markings |
Product Details
Typical Applications
- Mining-site water transportation
- mine-road dust suppression
- quarry dust control
- construction-site water supply
- construction-site dust control
- road construction
- highway maintenance
- municipal water transportation
- urban road watering
- industrial water transportation
- factory water supply
- construction-camp water supply
- port and terminal water supply
- agricultural water transportation
- farm irrigation
- landscape irrigation
- green-belt watering
- road washing
- municipal sanitation
- rural water supply
- remote-area water delivery
- emergency water supply.
Available Configurations
- 340HP, 375HP, 380HP, 400HP or 420HP diesel engine
- SHACMAN F3000 6×4 or 8×4 heavy-duty chassis
- Weichai or Cummins diesel engine
- left-hand drive or right-hand drive
- Euro II / Euro III / Euro IV / Euro V configuration according to chassis
- FAST 10-speed or 12-speed manual transmission
- 15CBM, 20CBM, 25CBM or 30CBM water tank
- Q235 carbon-steel, high-strength steel or stainless-steel tank
- customized tank-body and tank-head thickness
- single-compartment or multi-compartment tank
- multiple internal anti-wave baffles
- PTO-driven self-priming centrifugal water pump
- customized pump flow and pump head
- self-suction filling
- external pressure filling
- pump discharge
- gravity discharge
- pure water tanker configuration
- front sprinkler
- rear sprinkler
- side sprinkler
- duckbill nozzles
- rear water cannon
- high-pressure water cannon
- front and rear road-flushing system
- mine-road dust-suppression system
- construction-site sprinkler system
- municipal road sprinkler system
- landscape irrigation system
- hose reel
- hand spray gun
- fire-fighting connection
- mechanical or electronic water-level indicator
- stainless-steel valves and pipelines
- internal anti-corrosion coating
- rear working platform
- pump compartment
- hose storage box
- reversing camera
- rear working camera
- 360° monitoring system
- LED warning lights
- toolbox
- customized tank capacity, water system, paint color, company logo and export markings.
Buyer Support
- SHACMAN F3000 Water Tanker Truck combines a heavy-duty SHACMAN chassis with a large-capacity water tank for demanding mining, construction, municipal and industrial applications. 340HP, 375HP, 380HP, 400HP and 420HP engine configurations provide strong power for fully loaded operation on highways, construction roads, mining roads and rough working environments. 6×4 and 8×4 chassis configurations provide different payload levels for medium- and high-volume water transportation. Approximately 15–25CBM tanks can be configured for common 6×4 applications, while 8×4 chassis can support approximately 20–30CBM water tanks for projects requiring greater transport capacity. The vehicle can be supplied as a pure water tanker when the main requirement is bulk-water loading, transportation and discharge. This configuration reduces unnecessary upper-body equipment and is suitable for mining camps, construction projects, industrial facilities, agricultural operations and remote-area water delivery. For customers requiring road watering or dust suppression, a complete water sprinkler system can be added as an option. Front sprinklers, rear sprinklers, side sprays, duckbill nozzles, road-flushing equipment and rear water cannons can be configured for mine roads, construction sites, municipal streets and industrial areas. The PTO-driven self-priming centrifugal pump allows the truck to draw water directly from reservoirs, ponds, storage tanks and other external water sources. Pump discharge and gravity discharge provide flexible water-delivery methods for projects where fixed water-supply infrastructure is limited. Multiple internal anti-wave baffles help reduce water surge during acceleration, braking and cornering, improving stability during loaded transportation. The reinforced tanker subframe and heavy-duty F3000 chassis provide structural support for repeated operation with large-capacity water tanks. Carbon-steel tanks provide a durable and cost-effective solution for mining, construction and general industrial water transportation, while stainless-steel tanks can be selected for applications requiring improved corrosion resistance or cleaner water-storage conditions. Left-hand-drive and right-hand-drive configurations are available for different export markets. Engine power, drive configuration, tank capacity, tank material, tank thickness, water pump, piping system, sprinkler equipment, water cannon, filling and discharge system, monitoring equipment, paint color and other specifications can be customized according to project requirements.
