HOWO Wrecker Truck 115 / 160 / 300HP 3 / 5 / 8 / 10T Available
HOWO Wrecker Truck is a specialized road-rescue and vehicle-recovery truck designed for towing, lifting, transporting and recovering passenger vehicles, SUVs, vans, light trucks and medium commercial vehicles. The vehicle combines a reliable SINOTRUK HOWO chassis with a hydraulic sliding flatbed, wheel-lift underlift system, hydraulic winch, reinforced subframe and electro-hydraulic control system, allowing damaged or disabled vehicles to be safely loaded, lifted and transported. Different HOWO chassis configurations are available for light- and medium-duty recovery applications. Common 4×2 platforms can be configured with approximately 115HP, 160HP and 300HP diesel engines according to chassis size and recovery requirements. A representative HOWO 4×2 towing truck uses a 3,800mm wheelbase, 5,560×2,280mm flatbed, 3,000kg flatbed payload, 1,500kg maximum under-pulling capacity and 4-ton hydraulic winch. The hydraulic flatbed can slide backward and tilt toward the ground to provide a low loading angle, while the winch pulls a disabled vehicle onto the platform. The rear wheel-lift system can raise one axle of another vehicle for short- or medium-distance towing. Flatbed-only, flatbed-with-underlift and one-to-two recovery configurations can be selected according to operating requirements.
- Tel+86 139 6411 3362
- WhatsApp+86 139 6411 3362
- Emailluisa@sdlvnengintel.com
Product Description
Product Specifications
| Item | Specification Range |
|---|---|
| Product Type | Wrecker Truck / Tow Truck / Flatbed Recovery Truck / Road Rescue Truck |
| Brand | SINOTRUK HOWO |
| Chassis Brand | HOWO |
| Drive Type | 4×2 commonly available |
| Engine Power | 115HP / 160HP / 300HP available according to chassis and stock |
| Engine Brand | Yuchai / Weichai / Cummins / Yunnei / SINOTRUK or equivalent according to chassis |
| Engine Type | Four-cylinder / six-cylinder turbocharged and intercooled diesel engine |
| Fuel Type | Diesel |
| Emission Standard | Euro II / Euro III / Euro V / Euro VI available according to model year and export market |
| Transmission Type | Manual transmission |
| Transmission Gears | 6-speed / 8-speed / 10-speed manual transmission according to chassis |
| Common Light-Duty Transmission | WLY 6-speed or equivalent |
| Common Medium-Duty Transmission | FAST / SINOTRUK 8-speed or equivalent |
| Common Heavy 4×2 Transmission | HW19710 or equivalent |
| PTO | Power take-off for hydraulic recovery system |
| Cab Type | 1880 / 2080 / HW76 or equivalent HOWO cab according to chassis |
| Seating Capacity | 2–3 persons |
| Sleeper | Available on selected medium-duty configurations |
| Steering | Left-hand drive or right-hand drive optional |
| Power Steering | Available |
| Air Conditioner | Available / optional |
| Overall Length | Approx. 6,000–9,500 mm depending on chassis and recovery body |
| Overall Width | Approx. 2,200–2,550 mm |
| Overall Height | Approx. 2,400–3,300 mm |
| Wheelbase | Approx. 3,300–4,600 mm |
| Representative Wheelbase | 3,800 mm |
| Gross Vehicle Weight | Approx. 7–18 tons depending on chassis |
| Curb Weight | Approx. 4–10 tons depending on recovery equipment |
| Maximum Driving Speed | Approx. 90–105 km/h |
| Front Axle | HOWO steering axle according to chassis |
| Front Axle Capacity | Approx. 2.4–7.1 tons depending on chassis |
| Rear Axle | HOWO single drive axle |
| Rear Axle Capacity | Approx. 4.2–16 tons depending on chassis |
| Frame | Reinforced high-strength steel chassis frame |
| Recovery Subframe | Reinforced wrecker special-purpose subframe |
| Front Suspension | Leaf spring suspension |
| Rear Suspension | Reinforced multi-leaf spring suspension |
| Tire Model | 7.50R16 / 9.00R20 / 295/80R22.5 or equivalent according to chassis |
| Tire Quantity | 6 tires + spare tire |
| Fuel Tank | Approx. 120–400 L depending on chassis |
| Brake System | Hydraulic / dual-circuit compressed-air brake system according to chassis |
| ABS | Available according to chassis |
| Electrical System | 24V |
| Recovery Structure | Hydraulic sliding flatbed + wheel-lift underlift |
| Flatbed Type | Hydraulic sliding and tilting flatbed |
| Flatbed Payload | Approx. 3–10 tons depending on chassis and recovery body |
| Representative Flatbed Payload | 3,000 kg |
| Flatbed Length | Approx. 5,500–7,000 mm |
| Flatbed Width | Approx. 2,280–2,500 mm |
| Representative Flatbed Size | 5,560 × 2,280 mm |
| Flatbed Material | High-strength steel |
| Flatbed Surface | Anti-skid steel plate / checkered steel plate optional |
| Flatbed Extension | Optional |
| Flatbed Loading Angle | Low-angle hydraulic loading design |
| Underlift Type | Hydraulic telescopic wheel-lift |
| Underlift Capacity | Approx. 1.5–5 tons depending on recovery system |
| Representative Under-Pulling Capacity | 1,500 kg |
| Underlift Effective Length | Approx. 1,600–2,500 mm depending on configuration |
| Representative Tow Arm Length | 1,640 mm |
| Underlift Extension | Hydraulic telescopic extension |
| Underlift Tilt | Hydraulic adjustment |
| Wheel Fork | Adjustable wheel forks |
| Tow Bar | Optional |
| Hydraulic Winch | Available |
| Winch Quantity | Single / dual winch optional |
| Winch Capacity | Approx. 4–10 tons depending on recovery configuration |
| Representative Winch Capacity | 4 tons |
| Steel Wire Rope | Heavy-duty steel wire rope |
| Winch Control | Hydraulic control |
| Winch Free-Spool | Optional |
| Hydraulic Pump | PTO-driven hydraulic gear pump |
| Hydraulic Working Pressure | Approx. 16–25 MPa depending on system |
| Hydraulic Cylinder | Heavy-duty double-acting hydraulic cylinders |
| Hydraulic Control Valve | Multi-way hydraulic control valve |
| Hydraulic Oil Tank | Available |
| Flatbed Sliding | Hydraulic |
| Flatbed Tilting | Hydraulic |
| Underlift Extension | Hydraulic |
| Underlift Lifting | Hydraulic |
| Vehicle Loading | Hydraulic winch pulling |
| Vehicle Unloading | Hydraulic flatbed tilting and sliding |
| One-to-One Recovery | Available |
| One-to-Two Recovery | Optional |
| Wheel Dolly | Optional |
| Auxiliary Tow Wheels | Optional |
| Wheel Straps | Available / optional |
| Safety Chains | Available |
| Tow Forks | Available |
| Fork Holders | Available |
| Recovery Shackles | Optional |
| Pulley / Snatch Block | Optional |
| Emergency Manual Pump | Optional |
| Operation Control | Manual hydraulic / electro-hydraulic control |
| External Control | Available |
| Wireless Remote Control | Optional |
| Cab-Mounted Control | Optional |
| Reversing Camera | Optional |
| Rear Working Camera | Optional |
| 360° Monitoring System | Optional |
| LED Warning Light Bar | Optional |
| Rear Warning Lights | Optional |
| Search Light | Optional |
| Working Lights | Optional |
| Traffic Cones | Optional |
| Toolbox | Available |
| Fire Extinguisher | Available / optional |
| Spare Tire | Available |
| Color | White, yellow, blue, red, orange, green or customized |
| Condition | Used / Refurbished / Customized according to stock |
| Customization | Chassis, engine, flatbed size, flatbed capacity, underlift capacity, winch capacity, hydraulic system, towing accessories, steering side, tires, cameras, warning lights, paint color, company logo and export markings |
Product Details
Typical Applications
- Urban roadside rescue
- highway breakdown recovery
- passenger-car towing
- SUV recovery
- van recovery
- pickup-truck recovery
- light commercial vehicle towing
- light-truck recovery
- accident vehicle transportation
- disabled vehicle recovery
- municipal road rescue
- traffic-police support
- insurance roadside assistance
- towing-company operations
- automobile repair-shop recovery
- dealership vehicle transportation
- logistics-fleet roadside support
- rental-car recovery
- parking enforcement
- vehicle relocation
- emergency road service.
Available Configurations
- 115HP, 160HP or 300HP diesel engine
- 4×2 HOWO chassis
- Yuchai, Weichai, Cummins, Yunnei, SINOTRUK or equivalent engine according to chassis
- left-hand drive or right-hand drive
- Euro II / Euro III / Euro V / Euro VI emission configuration according to chassis
- 6-speed, 8-speed or 10-speed manual transmission
- approximately 3T, 5T, 8T or 10T flatbed recovery capacity
- approximately 5.5–7.0m hydraulic sliding flatbed
- anti-skid steel flatbed
- hydraulic telescopic underlift
- adjustable wheel forks
- approximately 1.5–5T underlift capacity
- single or dual hydraulic winch
- approximately 4–10T winch capacity
- steel wire rope
- tow forks
- safety chains
- wheel straps
- auxiliary wheel dolly
- snatch block
- hydraulic flatbed extension
- electro-hydraulic operation
- wireless remote control
- emergency manual hydraulic pump
- reversing camera
- rear working camera
- 360° monitoring system
- LED warning light bar
- search light
- traffic cones
- toolbox
- fire extinguisher
- spare tire
- customized recovery capacity, flatbed dimensions, towing equipment, paint color, company logo and export markings.
Buyer Support
- HOWO Wrecker Truck combines a reliable SINOTRUK HOWO commercial chassis with a professional hydraulic flatbed and wheel-lift recovery system for urban roadside rescue, highway towing and vehicle transportation
- different light- and medium-duty 4×2 chassis configurations provide flexible solutions for passenger cars, SUVs, vans, pickups and commercial vehicles. The hydraulic sliding flatbed allows damaged or non-running vehicles to be pulled onto the platform using a hydraulic winch, reducing the need for additional loading equipment
- adjustable flatbed tilt provides a lower loading angle for vehicles with damaged wheels, low ground clearance or limited mobility. The rear hydraulic underlift allows another vehicle to be lifted by its wheels or axle for towing, enabling flatbed transport and wheel-lift towing to be combined in one recovery vehicle. A representative HOWO 4×2 towing truck provides a 5,560×2,280mm flatbed, 3,000kg flatbed payload, 1,500kg under-pulling capacity and 4-ton winch. Different flatbed, underlift and winch capacities can be selected to match vehicle type and recovery workload
- single-winch and dual-winch systems, wheel dollies, tow forks, wheel straps, safety chains and other professional recovery accessories are available for different rescue operations. The reinforced HOWO chassis, recovery subframe and hydraulic system provide stable support for frequent loading, towing and unloading operations
- hydraulic controls simplify flatbed sliding, platform tilting, underlift lifting and vehicle recovery work. Left-hand-drive and right-hand-drive versions are available for different export markets
- engine, flatbed dimensions, recovery capacity, underlift system, winch capacity, hydraulic controls, towing accessories, monitoring cameras, warning equipment, paint color and other configurations can be customized according to roadside-rescue and towing-company requirements.
