HOWO Water Tanker Truck 266 / 336 / 371 / 380 / 400HP 10 / 15 / 20 / 25 / 30CBM Available – Water Sprinkler Optional
HOWO Water Tanker Truck is a heavy-duty water transportation vehicle designed for transporting clean water, industrial water and non-corrosive liquid media. The vehicle combines a durable SINOTRUK HOWO chassis with a high-strength steel water tank, reinforced subframe, water pump, piping system, valves and filling/discharge equipment for reliable water transportation in construction sites, mining areas, industrial projects, farms and remote locations. The vehicle can be supplied as a pure water tanker for water transportation and discharge only, or equipped with a complete water sprinkler system for road watering, dust suppression, construction-site spraying, mine-road dust control, landscape irrigation and municipal cleaning. Customers can select the upper-body configuration according to actual operating requirements without changing the basic vehicle platform. HOWO water tanker trucks are available with 4×2, 6×4 and 8×4 chassis configurations and approximately 10CBM to 30CBM tank capacities. Engine options including 266HP, 336HP, 371HP, 380HP and 400HP are available according to chassis, model year and stock. Tank volume, tank material, pump capacity, sprinkler equipment and piping layout can be customized for different export markets and projects.
- Tel+86 139 6411 3362
- WhatsApp+86 139 6411 3362
- Emailluisa@sdlvnengintel.com
Product Description
Product Specifications
| Item | Specification Range |
|---|---|
| Product Type | Water Tanker Truck / Water Bowser Truck / Water Transport Truck / Water Sprinkler Truck |
| Brand | SINOTRUK HOWO |
| Chassis Brand | HOWO |
| Drive Type | 4×2 / 6×4 / 8×4 available |
| Engine Power | 266HP / 336HP / 371HP / 380HP / 400HP available according to chassis and stock |
| Engine Brand | SINOTRUK / Weichai |
| Engine Type | Inline six-cylinder turbocharged and intercooled diesel engine |
| Fuel Type | Diesel |
| Emission Standard | Euro II / Euro III / Euro IV / Euro V available according to model year and export market |
| Transmission Brand | SINOTRUK |
| Transmission Type | Manual transmission |
| Common Transmission | HW19710 / HW19712 or equivalent |
| Transmission Gears | 10-speed / 12-speed manual transmission |
| PTO | Available for water pump drive |
| Cab Type | HOWO HW76 / TX / NX or equivalent HOWO cab according to chassis |
| Seating Capacity | 2–3 persons |
| Sleeper | Available according to cab configuration |
| Steering | Left-hand drive / right-hand drive optional |
| Power Steering | Hydraulic power steering |
| Air Conditioner | Available / optional |
| Overall Length | Approx. 7,500–12,000 mm depending on chassis and tank capacity |
| Overall Width | Approx. 2,400–2,550 mm |
| Overall Height | Approx. 3,000–3,700 mm |
| Wheelbase | Multiple wheelbase configurations available according to 4×2 / 6×4 / 8×4 chassis |
| Gross Vehicle Weight | Approx. 16–40 tons depending on chassis |
| Curb Weight | Approx. 8–17 tons depending on tank and equipment |
| Rated Payload | According to chassis, tank capacity and local certification |
| Maximum Driving Speed | Approx. 80–100 km/h |
| Front Axle | HOWO heavy-duty steering axle |
| Rear Axle | HOWO / MC-series heavy-duty drive axle |
| Rear Axle Type | Single-reduction / hub-reduction available |
| Differential Lock | Available on selected heavy-duty chassis |
| Frame | Reinforced high-strength steel chassis frame |
| Tank Subframe | Reinforced water-tanker special-purpose subframe |
| Front Suspension | Multi-leaf spring suspension |
| Rear Suspension | Reinforced multi-leaf spring / balance suspension |
| Tire Model | 11.00R20 / 12.00R20 / 315/80R22.5 or equivalent |
| Tire Quantity | According to 4×2 / 6×4 / 8×4 chassis |
| Spare Tire | Available |
| Fuel Tank | Approx. 300–500 L according to chassis |
| Brake System | Dual-circuit compressed-air brake system |
| Parking Brake | Spring-energy compressed-air brake |
| Auxiliary Brake | Engine exhaust brake available |
| ABS | Available according to chassis |
| Electrical System | 24V |
| Tank Capacity | 10CBM / 15CBM / 20CBM / 25CBM / 30CBM available |
| Common 4×2 Tank Capacity | Approx. 10–15 CBM |
| Common 6×4 Tank Capacity | Approx. 15–25 CBM |
| Common 8×4 Tank Capacity | Approx. 20–30 CBM |
| Tank Shape | Elliptical / oval cylindrical tank |
| Tank Material | Q235 carbon steel / stainless steel optional |
| Carbon Steel Tank | Available |
| Stainless Steel Tank | Optional |
| Tank Body Thickness | Approx. 4–6 mm or customized |
| Tank Head Thickness | Approx. 5–7 mm or customized |
| Anti-Wave Baffles | Multiple internal anti-wave baffles |
| Baffle Material | Same or equivalent material as tank body |
| Tank Compartments | Single compartment standard / multiple compartments optional |
| Manhole | Available on top of tank |
| Manhole Cover | Bolt-type / quick-opening cover optional |
| Ladder | Rear / side climbing ladder available |
| Top Walkway | Anti-slip walkway optional |
| Tank Guardrail | Optional |
| Water Pump | Available |
| Pump Type | Self-priming centrifugal water pump |
| Pump Drive | PTO-driven |
| Pump Flow Rate | Approx. 40–80 m³/h depending on pump |
| Pump Head | Approx. 45–90 m depending on pump configuration |
| Self-Priming Function | Available |
| Self-Suction Depth | Approx. 5–7 m depending on pump |
| Water Filling Method | Pump self-suction / external filling |
| Water Discharge Method | Pump discharge / gravity discharge |
| Pump Inlet | Available |
| Pump Outlet | Available |
| Suction Hose | Optional / available |
| Suction Hose Length | Approx. 5–8 m or customized |
| Fire Hose Connection | Optional |
| External Water Connection | Optional |
| Gravity Discharge Valve | Available |
| Ball Valve | Available |
| Stainless Steel Valve | Optional |
| Pipe Material | Carbon steel / galvanized steel / stainless steel optional |
| Pure Water Tanker Configuration | Available |
| Water Sprinkler Configuration | Optional |
| Front Sprinkler | Optional |
| Rear Sprinkler | Optional |
| Side Sprinkler | Optional |
| Front Duckbill Nozzle | Optional |
| Rear Spraying Nozzle | Optional |
| Sprinkling Width | Approx. 14–20 m depending on configuration |
| Rear Water Cannon | Optional |
| Water Cannon Range | Approx. 25–35 m depending on pressure and nozzle |
| Cannon Rotation | Adjustable / rotating |
| Cannon Spray Pattern | Column / heavy rain / moderate rain / drizzle adjustable |
| High-Pressure Water Cannon | Optional |
| Side Spray System | Optional |
| Dust Suppression Spray | Optional |
| Low-Pressure Sprinkler System | Optional |
| High-Pressure Cleaning System | Optional |
| Front Flushing Nozzle | Optional |
| Rear Flushing Nozzle | Optional |
| Road Washing Function | Optional |
| Green-Belt Irrigation Function | Optional |
| Fire-Fighting Interface | Optional |
| Hose Reel | Optional |
| Hand Spray Gun | Optional |
| Water Level Indicator | Mechanical / electronic optional |
| Liquid Level Gauge | Optional |
| Overflow Pipe | Available |
| Drainage Outlet | Available |
| Bottom Drain Valve | Available |
| Tank Cleaning Port | Available |
| Internal Anti-Corrosion Coating | Optional |
| External Anti-Corrosion Treatment | Primer + industrial topcoat |
| Food-Grade Tank Treatment | Optional for suitable water applications |
| Stainless Steel Interior | Optional |
| Rear Working Platform | Optional |
| Pump Compartment | Optional |
| Toolbox | Available / optional |
| Hose Storage Box | Optional |
| Rear Working Lights | Optional |
| LED Warning Lights | Optional |
| Reversing Camera | Optional |
| Rear Working Camera | Optional |
| 360° Monitoring System | Optional |
| Fire Extinguisher | Available / optional |
| Color | White, blue, green, yellow, red, orange or customized |
| Condition | Used / Refurbished / Customized according to stock |
| Customization | Chassis, engine, drive type, tank capacity, tank material, steel thickness, pump model, piping system, sprinkler system, water cannon, filling/discharge system, steering side, cameras, warning equipment, paint color, company logo and export markings |
Product Details
Typical Applications
- Clean-water transportation
- construction-site water supply
- mining-site water transportation
- mine-road dust suppression
- road construction
- highway maintenance
- municipal water transportation
- urban road watering
- rural water supply
- remote-area water delivery
- industrial water transportation
- factory water supply
- port and terminal water supply
- construction-camp water supply
- agricultural water transportation
- farm irrigation
- landscape irrigation
- green-belt watering
- road dust suppression
- construction-site dust control
- road washing
- municipal sanitation
- emergency water supply.
Available Configurations
- 266HP, 336HP, 371HP, 380HP or 400HP diesel engine
- HOWO 4×2, 6×4 or 8×4 chassis
- left-hand drive or right-hand drive
- Euro II / Euro III / Euro IV / Euro V configuration according to chassis
- HW19710, HW19712 or equivalent manual transmission
- 10CBM, 15CBM, 20CBM, 25CBM or 30CBM water tank
- Q235 carbon-steel tank or stainless-steel tank
- customized tank-body and tank-head thickness
- single-compartment or multi-compartment tank
- internal anti-wave baffles
- self-priming centrifugal water pump
- customized pump flow and head
- self-suction system
- gravity discharge system
- external water filling
- suction hose
- fire hose connector
- pure water tanker configuration
- front sprinkler
- rear sprinkler
- side sprinkler
- duckbill sprinkler
- rear water cannon
- high-pressure water cannon
- dust-suppression spray system
- road washing system
- front flushing nozzles
- rear flushing nozzles
- landscape irrigation system
- hose reel
- hand spray gun
- fire-fighting connection
- electronic water-level indicator
- stainless-steel valves
- stainless-steel piping
- anti-corrosion tank coating
- rear working platform
- pump compartment
- toolbox
- hose storage box
- reversing camera
- rear working camera
- 360° monitoring system
- LED warning lights
- customized paint color, company logo and export markings.
Buyer Support
- HOWO Water Tanker Truck combines a durable SINOTRUK HOWO heavy-duty chassis with a large-capacity water tank for reliable water transportation in construction, mining, municipal, industrial and agricultural applications. 4×2, 6×4 and 8×4 chassis configurations provide different payload levels, while 266HP, 336HP, 371HP, 380HP and 400HP engine options can meet different tank capacities, road conditions and project requirements. The vehicle can be configured as a pure water tanker when the primary requirement is water transportation. This version focuses on tank capacity, filling efficiency, water discharge and transportation reliability, without unnecessary sprinkler equipment, making it suitable for construction camps, industrial projects, remote water supply, farms and other bulk-water transportation operations. A complete water sprinkler system can also be added as an option. Front, rear and side sprinklers, duckbill nozzles, rear water cannon, road-flushing nozzles and irrigation equipment can be configured for road watering, mining dust suppression, construction-site dust control, municipal sanitation and landscape irrigation. 10CBM, 15CBM, 20CBM, 25CBM and 30CBM tank capacities are available for different transport requirements. Internal anti-wave baffles reduce liquid movement during acceleration, braking and cornering, improving vehicle stability when transporting large volumes of water. The PTO-driven self-priming water pump allows the truck to draw water directly from reservoirs, ponds or external storage facilities and also provides pressurized discharge. Gravity discharge, pump discharge, external filling and multiple hose connections can be configured to suit different water-supply conditions. Carbon-steel tanks provide an economical and durable solution for construction, mining and general industrial water transportation, while stainless-steel tanks can be selected for applications requiring greater corrosion resistance or higher water-quality standards. Left-hand-drive and right-hand-drive versions are available for different export markets. Chassis model, engine power, tank volume, tank material, tank thickness, water pump, piping, sprinkler equipment, water cannon, filling and discharge system, paint color and other configurations can be customized according to project requirements.
