HOWO TX Water Tanker Truck 340 / 380 / 400 / 430HP 10 / 15 / 20 / 25 / 30CBM Available – Water Sprinkler Optional
HOWO TX Water Tanker Truck is a medium- and heavy-duty water transportation vehicle designed for construction sites, mining operations, municipal projects, industrial facilities, agriculture and remote-area water supply. The vehicle combines a SINOTRUK HOWO TX chassis with a reinforced large-capacity water tank, PTO-driven water pump, pipelines, valves and filling/discharge equipment for reliable bulk-water transportation. The truck can be supplied as a pure water tanker for water loading, transportation and discharge, or equipped with an optional water sprinkler system for road watering, mine-road dust suppression, construction-site dust control, municipal cleaning and landscape irrigation. The sprinkler equipment is modular, allowing customers to select only the functions required for their operating conditions. HOWO TX water tanker trucks are available with 4×2, 6×4 and 8×4 chassis configurations. Engine options include approximately 340HP, 380HP, 400HP and 430HP, while tank capacities ranging from approximately 10CBM to 30CBM can be selected according to chassis, payload requirements and local regulations. Carbon-steel and stainless-steel tanks are available for different water-quality and corrosion-resistance requirements.
- Tel+86 139 6411 3362
- WhatsApp+86 139 6411 3362
- Emailluisa@sdlvnengintel.com
Product Description
Product Specifications
| Item | Specification Range |
|---|---|
| Product Type | Water Tanker Truck / Water Bowser Truck / Water Transport Truck / Water Sprinkler Truck |
| Brand | SINOTRUK HOWO |
| Chassis Series | HOWO TX |
| Drive Type | 4×2 / 6×4 / 8×4 available |
| Engine Power | 340HP / 380HP / 400HP / 430HP available according to chassis and stock |
| Engine Brand | SINOTRUK / Weichai |
| Engine Type | Inline six-cylinder turbocharged and intercooled diesel engine |
| Fuel Type | Diesel |
| Emission Standard | Euro III / Euro V / Euro VI available according to chassis and export market |
| Transmission Brand | SINOTRUK |
| Transmission Type | Manual transmission |
| Common Transmission | HW19710 / HW19712 or equivalent |
| Transmission Gears | 10-speed / 12-speed manual transmission |
| PTO | Available for water-pump operation |
| Cab Series | HOWO TX |
| Cab Type | TX standard / high-roof cab according to chassis |
| Seating Capacity | 2–3 persons |
| Sleeper | Available |
| Driver Seat | Adjustable / air-suspension driver seat available |
| Steering | Left-hand drive / right-hand drive optional |
| Power Steering | Hydraulic power steering |
| Air Conditioner | Available |
| Overall Length | Approx. 7,500–12,000 mm depending on chassis and tank capacity |
| Overall Width | Approx. 2,400–2,550 mm |
| Overall Height | Approx. 3,000–3,800 mm |
| Wheelbase | Multiple wheelbase configurations available according to 4×2 / 6×4 / 8×4 chassis |
| Gross Vehicle Weight | Approx. 18–40 tons depending on chassis |
| Curb Weight | Approx. 9–18 tons depending on tank and equipment |
| Rated Payload | According to chassis, tank capacity and local certification |
| Maximum Driving Speed | Approx. 80–100 km/h |
| Front Axle | SINOTRUK heavy-duty steering axle |
| Rear Axle | SINOTRUK / MC-series heavy-duty drive axle |
| Rear Axle Type | Single-reduction / hub-reduction available |
| Differential Lock | Available on selected chassis |
| Frame | Reinforced high-strength steel chassis frame |
| Tank Subframe | Reinforced tanker special-purpose subframe |
| Front Suspension | Multi-leaf spring suspension |
| Rear Suspension | Heavy-duty multi-leaf spring / balance suspension |
| Tire Model | 11.00R20 / 12.00R20 / 12R22.5 / 315/80R22.5 or equivalent |
| Tire Quantity | According to 4×2 / 6×4 / 8×4 chassis |
| Spare Tire | Available / optional |
| Fuel Tank | Approx. 300–500 L |
| Brake System | Dual-circuit compressed-air brake system |
| Parking Brake | Spring-energy compressed-air brake |
| Auxiliary Brake | Engine exhaust brake / engine brake available |
| ABS | Available |
| Electrical System | 24V |
| Tank Capacity | 10CBM / 15CBM / 20CBM / 25CBM / 30CBM available |
| Common 4×2 Tank Capacity | Approx. 10–15 CBM |
| Common 6×4 Tank Capacity | Approx. 15–25 CBM |
| Common 8×4 Tank Capacity | Approx. 20–30 CBM |
| Tank Shape | Elliptical / oval cylindrical tank |
| Tank Material | Q235 carbon steel / high-strength carbon steel / stainless steel optional |
| Carbon-Steel Tank | Available |
| Stainless-Steel Tank | Optional |
| Tank Body Thickness | Approx. 4–6 mm or customized |
| Tank Head Thickness | Approx. 5–7 mm or customized |
| Tank Compartments | Single compartment standard / multiple compartments optional |
| Internal Baffles | Multiple anti-wave baffles |
| Baffle Function | Reduces water surge during acceleration, braking and cornering |
| Manhole | Available |
| Manhole Cover | Bolt-type / quick-opening type optional |
| Tank Ladder | Available |
| Top Walkway | Anti-slip walkway optional |
| Top Guardrail | Optional |
| Water Pump | Available |
| Pump Type | Self-priming centrifugal water pump |
| Pump Drive | PTO-driven |
| Pump Flow | Approx. 40–80 m³/h depending on pump configuration |
| Pump Head | Approx. 45–90 m depending on pump |
| Self-Priming Function | Available |
| Self-Suction Depth | Approx. 5–7 m depending on pump |
| Water Filling | Pump self-suction / external pressure filling |
| Water Discharge | Pump discharge / gravity discharge |
| Gravity Discharge Valve | Available |
| Water Inlet | Available |
| Water Outlet | Available |
| Suction Hose | Available / optional |
| Suction Hose Length | Approx. 5–8 m or customized |
| Pipeline Material | Carbon steel / galvanized steel / stainless steel optional |
| Valve Material | Carbon steel / aluminum alloy / stainless steel optional |
| Pure Water Tanker Configuration | Available |
| Water Sprinkler Configuration | Optional |
| Front Sprinkler | Optional |
| Rear Sprinkler | Optional |
| Side Sprinkler | Optional |
| Front Duckbill Nozzle | Optional |
| Rear Spray Nozzle | Optional |
| Sprinkling Width | Approx. 14–20 m depending on configuration |
| Rear Water Cannon | Optional |
| Water Cannon Range | Approx. 25–35 m depending on pump pressure and nozzle |
| Water Cannon Rotation | Adjustable |
| Water Cannon Spray Pattern | Column / heavy rain / moderate rain / mist adjustable |
| High-Pressure Water Cannon | Optional |
| Front Flushing System | Optional |
| Rear Flushing System | Optional |
| Side Spray System | Optional |
| Road Washing System | Optional |
| Dust Suppression System | Optional |
| Mine-Road Dust Control | Optional |
| Construction-Site Dust Control | Optional |
| Landscape Irrigation System | Optional |
| Green-Belt Watering | Optional |
| Hand Spray Gun | Optional |
| High-Pressure Spray Gun | Optional |
| Hose Reel | Optional |
| Fire Hose Connection | Optional |
| Fire-Fighting Interface | Optional |
| Water Level Gauge | Mechanical / electronic optional |
| Electronic Level Indicator | Optional |
| Overflow Pipe | Available |
| Tank Drain Outlet | Available |
| Bottom Drain Valve | Available |
| Tank Cleaning Port | Available |
| Internal Anti-Corrosion Coating | Optional |
| External Anti-Corrosion Treatment | Primer + industrial topcoat |
| Stainless-Steel Inner Tank | Optional |
| Rear Working Platform | Optional |
| Pump Compartment | Optional |
| Hose Storage Box | Optional |
| Toolbox | Available / optional |
| Rear Working Lights | Optional |
| LED Warning Lights | Optional |
| Reversing Camera | Optional |
| Rear Working Camera | Optional |
| 360° Monitoring System | Optional |
| Fire Extinguisher | Available / optional |
| Color | White, blue, green, yellow, red, orange or customized |
| Condition | Used / Refurbished / Customized according to stock |
| Customization | Engine, drive type, tank capacity, tank material, steel thickness, pump, pipeline system, sprinkler equipment, water cannon, filling/discharge system, steering side, cameras, warning equipment, paint color, company logo and export markings |
Product Details
Typical Applications
- Construction-site water supply
- mining-site water transportation
- mine-road dust suppression
- quarry dust control
- road construction
- highway maintenance
- municipal water transportation
- urban road watering
- industrial water transportation
- factory water supply
- construction-camp water supply
- port and terminal water supply
- agricultural water transportation
- farm irrigation
- landscape irrigation
- green-belt watering
- road dust suppression
- construction-site dust control
- road washing
- municipal sanitation
- rural water supply
- remote-area water delivery
- emergency water supply.
Available Configurations
- 340HP, 380HP, 400HP or 430HP diesel engine
- HOWO TX 4×2, 6×4 or 8×4 chassis
- left-hand drive or right-hand drive
- Euro III / Euro V / Euro VI configuration according to chassis
- 10-speed or 12-speed SINOTRUK manual transmission
- 10CBM, 15CBM, 20CBM, 25CBM or 30CBM water tank
- Q235 carbon-steel, high-strength steel or stainless-steel tank
- customized tank-body and tank-head thickness
- single-compartment or multi-compartment structure
- multiple anti-wave baffles
- self-priming centrifugal water pump
- customized pump flow and pump head
- self-suction filling
- external filling
- gravity discharge
- pump discharge
- pure water tanker configuration
- front sprinkler
- rear sprinkler
- side sprinkler
- duckbill nozzles
- rear water cannon
- high-pressure water cannon
- front and rear road-flushing system
- dust-suppression spray system
- mine-road sprinkler system
- landscape irrigation system
- hose reel
- hand spray gun
- fire-fighting connection
- electronic water-level indicator
- stainless-steel valves and pipelines
- internal anti-corrosion coating
- rear working platform
- pump compartment
- hose storage box
- reversing camera
- rear working camera
- 360° monitoring system
- LED warning lights
- toolbox
- customized tank capacity, water system, paint color, company logo and export markings.
Buyer Support
- HOWO TX Water Tanker Truck combines the SINOTRUK HOWO TX chassis with a large-capacity water tank and professional water-transfer system for construction, mining, municipal, industrial and agricultural projects. 340HP, 380HP, 400HP and 430HP engine configurations provide strong power for different water capacities and road conditions. 4×2, 6×4 and 8×4 chassis configurations allow the HOWO TX platform to cover a wider range of water-transport requirements. 4×2 versions are suitable for approximately 10–15CBM urban and medium-duty applications, while 6×4 and 8×4 configurations can support approximately 15–30CBM tanks for mining, construction and high-volume water transportation. The vehicle can be supplied as a pure water tanker, focusing on water loading, bulk transportation and rapid discharge without unnecessary spraying equipment. This configuration is suitable for construction camps, industrial plants, mining projects, agricultural operations and remote-area water delivery. An optional water sprinkler package can be added for customers requiring road watering and dust control. Front sprinklers, rear sprinklers, side sprays, duckbill nozzles, road-flushing nozzles and rear water cannons can be selected according to the working environment. The PTO-driven self-priming centrifugal pump allows the vehicle to draw water from reservoirs, ponds, storage tanks and other external water sources. Pump discharge and gravity discharge provide flexible water-delivery methods where fixed pumping infrastructure may not be available. Internal anti-wave baffles reduce water surge inside the tank during braking, acceleration and cornering, improving stability during loaded transportation. Different tank capacities, steel thicknesses and internal structures can be configured according to chassis payload and operating conditions. Carbon-steel tanks provide a cost-effective solution for construction, mining and general-purpose water transport, while stainless-steel tanks can be selected for applications requiring improved corrosion resistance or cleaner water-storage conditions. Left-hand-drive and right-hand-drive versions are available for different export markets. Engine power, drive configuration, tank volume, tank material, water pump, pipeline system, sprinkler equipment, water cannon, filling and discharge system, monitoring equipment, paint color and other specifications can be customized according to project requirements.
