Dump Trucks
HOWO T7H / TH7 8×4 Dump Truck 400 / 430 / 460 / 480 / 540HP Available
HOWO T7H / TH7 8×4 Dump Truck 430HP 460HP 480HP 540HP Heavy Duty Tipper Truck HOWO T7H / TH7 8×4 dump truck is a high-power heavy-duty tipper truck designed for large-volume bulk material transportation and rear tipping unloading. It is suitable for construction projects, mining areas, quarry operations, earthwork projects, road construction and infrastructure transportation. Compared with classic HOWO 8×4 dump trucks, the T7H / TH7 series offers a more modern cab design, stronger engine options, improved driving comfort and better adaptability for heavy-load working conditions. The 8×4 chassis provides a longer cargo body, larger loading volume and stable performance for heavy-duty material transport. Engine power, emission standard, cargo box size, tire model, driving side, color, logo and hydraulic lifting system can be customized according to stock condition and customer requirements.
- Tel+86 139 6411 3362
- WhatsApp+86 139 6411 3362
- Emailluisa@sdlvnengintel.com
Product Description
Product Specifications
| Item | Specification Range |
|---|---|
| Product Type | Dump Truck / Tipper Truck |
| Brand | SINOTRUK HOWO |
| Model Series | HOWO T7H / TH7 |
| Drive Type | 8×4 |
| Engine Power | 400HP / 430HP / 460HP / 480HP / 540HP available |
| Engine Brand | SINOTRUK / Weichai optional according to stock |
| Engine Model | MC11 / MC13 / WP12 / WP13 series optional |
| Emission Standard | Euro III / Euro V / Euro VI optional, Euro II according to export stock |
| Transmission | HW19712 / HW25712 / 12-speed manual transmission, AMT optional according to stock |
| Cab | T7H / TH7 cab, standard roof or high roof optional, sleeper optional |
| Steering | Left-hand drive or right-hand drive optional |
| Overall Dimension | Approx. 10,300-11,800 mm L × 2,496-2,550 mm W × 3,400-3,850 mm H |
| Wheelbase | Approx. 1,800-1,950 + 3,800-4,600 + 1,350 / 1,400 mm |
| Cargo Box Type | Rear dump body, rectangular box or U-shape box optional |
| Cargo Box Size | Approx. 7,000-8,500 mm L × 2,300-2,500 mm W × 1,200-2,000 mm H |
| Cargo Box Volume | Approx. 24-40 m³, depending on box size |
| Loading Capacity | Approx. 30-55 tons, depending on configuration and local regulations |
| Hydraulic System | Front lifting cylinder or middle lifting system optional |
| Axle Configuration | 2 front steering axles + 2 rear drive axles |
| Front Axle | VGD95 / 9.5T heavy-duty front axle optional |
| Rear Axle | MCX16 / MCP16 / MCY16 heavy-duty double rear drive axles optional |
| Suspension | Heavy-duty multi-leaf spring suspension |
| Tire Model | 12.00R20 / 12R22.5 / 13R22.5 / 315/80R22.5 optional |
| Tire Quantity | 12 tires + 1 spare tire |
| Fuel Tank | Approx. 300-600 L, steel or aluminum fuel tank optional |
| Brake System | Dual-circuit air brake system, ABS optional |
| Max Speed | Approx. 75-90 km/h, depending on configuration |
| Color | White, red, green, yellow or customized |
| Condition | Used / Refurbished / Customized according to stock |
| Customization | Engine, emission, cargo box, tires, color, logo, driving side, hydraulic system and accessories |
Product Details
Typical Applications
- Large construction material transportation
- sand, gravel and soil transport
- mining area material transfer
- coal and ore transportation
- quarry operation
- road construction projects
- earthwork projects
- infrastructure construction
- municipal engineering
- demolition waste transportation
- large-volume short and medium-distance bulk cargo transport.
Available Configurations
- 400HP, 430HP, 460HP, 480HP or 540HP engine
- MC11, MC13, WP12 or WP13 engine
- Euro III / Euro V / Euro VI emission standard
- left-hand drive or right-hand drive
- T7H cab or TH7 cab
- standard roof or high roof cab
- rectangular cargo box or U-shape cargo box
- different cargo box length, height and steel thickness
- front hydraulic lifting system or middle lifting system
- 12.00R20, 12R22.5, 13R22.5 or 315/80R22.5 tires
- reinforced rear axle
- air conditioner
- air suspension seat
- ABS
- spare tire
- customized paint color, logo and export markings.
Buyer Support
- HOWO T7H / TH7 8×4 dump truck offers a modern cab, strong power and heavy-duty chassis performance
- 8×4 drive type provides larger cargo volume and stronger loading capacity than 6×4 models
- 430HP, 460HP, 480HP and 540HP engine options are suitable for construction, mining, quarry and heavy earthwork transport
- reinforced dump body improves durability for sand, gravel, soil, coal and ore transport
- reliable hydraulic rear tipping system improves unloading efficiency
- heavy-duty axles and multi-leaf spring suspension are suitable for rough construction and mining roads
- T7H / TH7 cab provides better comfort, visibility and safety for long working hours
- multiple emission standards and driving-side options are available for different export markets
- used, refurbished and customized trucks can be supplied with flexible configuration and competitive cost performance.
Product Display
