HOWO Road Sweeper Truck 116 / 140 / 160 / 180HP Available
HOWO Road Sweeper Truck is a specialized municipal and industrial cleaning vehicle designed for street sweeping, dust collection, debris removal and road-surface cleaning. It combines a durable HOWO truck chassis with a professional sweeping system, vacuum suction system, water-spray dust suppression system, debris tank, water tank, hydraulic system and auxiliary power unit, allowing sweeping, suction and dust-control operations to be completed efficiently in a single working pass. The HOWO road sweeper is available with different chassis and superstructure configurations to meet urban sanitation, highway maintenance, industrial park, construction-site and municipal cleaning requirements. Common engine power options include 116HP, 140HP, 160HP and 180HP, while different wheelbases, tank capacities and sweeping systems are available according to operating conditions. The sweeping system normally uses hydraulically driven side brushes to move dust, sand, leaves, gravel and other road debris toward the suction nozzle. A high-pressure centrifugal fan generates strong vacuum suction to collect debris into the garbage tank, while water-spray nozzles suppress airborne dust during operation. Hydraulic garbage-tank lifting and rear-door opening systems provide convenient unloading and daily maintenance.
- Tel+86 139 6411 3362
- WhatsApp+86 139 6411 3362
- Emailluisa@sdlvnengintel.com
Product Description
Product Specifications
| Item | Specification Range |
|---|---|
| Product Type | Road Sweeper Truck / Street Sweeper Truck / Municipal Sweeper Truck / Road Cleaning Truck |
| Brand | SINOTRUK HOWO |
| Chassis Brand | HOWO |
| Drive Type | 4×2 commonly available |
| Engine Power | 116HP / 140HP / 160HP / 180HP available |
| Engine Brand | Yuchai / Yunnei / SINOTRUK or equivalent according to chassis |
| Engine Type | Four-cylinder turbocharged and intercooled diesel engine commonly available |
| Fuel Type | Diesel |
| Emission Standard | Euro II / Euro III / Euro V or other standards according to model year and export market |
| Transmission Type | Manual transmission |
| Transmission Gears | 5-speed / 6-speed manual transmission according to chassis |
| Cab Type | Single-row cab |
| Seating Capacity | 2–3 persons |
| Steering | Left-hand drive or right-hand drive optional |
| Power Steering | Available |
| Air Conditioner | Available / optional |
| Overall Length | Approx. 5,950–8,000 mm |
| Overall Width | Approx. 2,100–2,500 mm |
| Overall Height | Approx. 2,500–3,150 mm |
| Wheelbase | Approx. 3,300–4,700 mm |
| Gross Vehicle Weight | Approx. 8–14 tons |
| Curb Weight | Approx. 5,500–8,500 kg |
| Maximum Driving Speed | Approx. 90–100 km/h |
| Front Axle | HOWO steering axle according to chassis |
| Rear Axle | HOWO single drive axle according to chassis |
| Suspension | Front and rear leaf-spring suspension |
| Tire Model | 8.25R16 / 9.00R20 or equivalent according to chassis |
| Tire Quantity | 6 tires + spare tire |
| Brake System | Hydraulic or dual-circuit compressed-air brake system according to chassis |
| Electrical System | 24V |
| Sweeping System | Hydraulic sweeping brushes + vacuum suction system |
| Sweeping Brush Quantity | Commonly 4 sweeping brushes |
| Sweeping Brush Diameter | Approx. 850–900 mm |
| Brush Drive | Hydraulic motor drive |
| Brush Control | Hydraulic lifting and lowering |
| Maximum Sweeping Width | Approx. 2.8–3.5 m |
| Sweeping Speed | Approx. 3–20 km/h |
| Cleaning Capacity | Approx. 38,000–70,000 m²/h |
| Sweeping Efficiency | Approx. 90–96% |
| Suction System | Central / rear vacuum suction nozzle |
| Suction Nozzle Type | Floating suction nozzle / U-shaped suction nozzle optional |
| Suction Opening | Approx. 190–200 mm |
| Maximum Debris Size | Approx. 50–120 mm depending on suction system |
| Fan Type | High-pressure centrifugal fan |
| Fan Drive | Auxiliary diesel engine / hydraulic drive according to configuration |
| Auxiliary Engine | Independent diesel auxiliary engine available |
| Auxiliary Engine Power | Approx. 78–140HP depending on sweeper configuration |
| Debris Tank Capacity | Approx. 4–8 CBM |
| Water Tank Capacity | Approx. 1.5–3.5 CBM |
| Combined Tank Capacity | Approx. 5.5–11.5 CBM |
| Debris Tank Material | Stainless steel / reinforced corrosion-resistant steel optional |
| Water Tank Material | Stainless steel / 304 stainless steel optional |
| Dust Suppression System | Water-spray nozzles around sweeping area |
| Water Pump | Electric / hydraulic water pump according to configuration |
| Debris Tank Discharge | Hydraulic tipping |
| Tipping Angle | Approx. ≥40° |
| Rear Door | Hydraulic opening and closing |
| Hydraulic System | Hydraulic pump, motors, cylinders, control valves and hydraulic oil tank |
| Sweeper Control | Cab-mounted electric / electro-hydraulic control system |
| Working Mode | Sweeping + vacuum suction + water-spray dust suppression |
| Front Water Spray | Optional |
| Rear Sprinkler | Optional |
| Side Sprayer | Optional |
| High-Pressure Washing | Optional |
| Handheld Water Gun | Optional |
| Hose Reel | Optional |
| Debris Tank Self-Cleaning | Optional |
| Reversing Camera | Optional |
| Working-Area Camera | Optional |
| Warning System | LED warning lamp / rear arrow warning light optional |
| Toolbox | Available / optional |
| Spare Tire | Available |
| Color | White, blue, green, yellow or customized |
| Condition | Used / Refurbished / Customized according to stock |
| Customization | Engine, steering side, wheelbase, debris tank, water tank, tank material, sweeping system, suction system, auxiliary engine, water-spray system, camera, warning lights, paint color, company logo and export markings |
Product Details
Typical Applications
- Urban street cleaning
- municipal road sweeping
- highway cleaning
- industrial park cleaning
- factory road cleaning
- construction-site road cleaning
- residential-community cleaning
- airport service-road cleaning
- port and terminal cleaning
- logistics park cleaning
- warehouse-area cleaning
- public square cleaning
- parking-area cleaning
- campus road cleaning
- dust and sand removal
- fallen-leaf collection
- small debris collection
- roadside dust control
- municipal sanitation operations.
Available Configurations
- 116HP, 140HP, 160HP or 180HP diesel engine
- left-hand drive or right-hand drive
- Euro II / Euro III / Euro V emission configuration according to chassis
- approximately 3,300–4,700mm wheelbase
- 4–8CBM debris tank
- 1.5–3.5CBM water tank
- stainless-steel debris tank
- 304 stainless-steel water tank
- four-brush sweeping system
- hydraulically controlled sweeping brushes
- approximately 2.8–3.5m sweeping width
- independent auxiliary diesel engine
- high-pressure centrifugal fan
- floating suction nozzle
- U-shaped suction nozzle
- central or rear suction system
- water-spray dust suppression system
- front flushing system
- rear sprinkler
- side sprayer
- high-pressure washing system
- handheld water gun
- hose reel
- debris-tank self-cleaning system
- hydraulic debris-tank lifting
- hydraulic rear door
- reversing camera
- sweeping-operation monitoring camera
- rear LED warning arrow
- air conditioner
- toolbox
- spare tire
- customized tank volume, sweeping system, suction system, paint color, company logo and export markings.
Buyer Support
- HOWO Road Sweeper Truck combines a durable HOWO commercial chassis with a professional sweeping, vacuum suction and dust-suppression system for municipal and industrial road-cleaning applications
- 116HP, 140HP, 160HP and 180HP engine options are available to meet different vehicle sizes and operating requirements
- approximately 2.8–3.5m sweeping width provides efficient coverage for city streets, industrial roads and large paved areas
- hydraulically driven multi-brush sweeping systems guide dust, sand, leaves and debris toward the suction nozzle for efficient collection
- high-pressure centrifugal vacuum fans provide strong suction performance for common road debris
- independent auxiliary-engine configurations provide stable power for the sweeping and suction systems
- 4–8CBM debris tanks and 1.5–3.5CBM water tanks are available for different sanitation workloads
- water-spray dust suppression reduces airborne dust during sweeping operations
- hydraulic debris-tank lifting and rear-door opening simplify unloading and cleaning
- stainless-steel tank options provide improved corrosion resistance for long-term sanitation use
- left-hand-drive and right-hand-drive configurations are available for different export markets
- sweeping brushes, suction system, tank volume, auxiliary engine, high-pressure washing system, cameras, warning lights, paint color and other configurations can be customized according to project requirements.
