Special Trucks
HOWO NX Concrete Mixer Truck 340 / 380 / 400HP 8 / 9 / 10 / 12CBM Available
HOWO NX Concrete Mixer Truck is a heavy-duty concrete transportation vehicle designed for ready-mixed concrete plants, construction contractors and infrastructure projects. It combines the HOWO NX heavy-duty chassis with a high-strength mixing drum, hydraulic drive system, reducer, hydraulic pump, hydraulic motor, feeding hopper, discharge chute and water-cleaning system, providing reliable concrete agitation and transportation between batching plants and construction sites. The HOWO NX platform is available with multiple Weichai and SINOTRUK diesel engine configurations. Common heavy-duty power options include 340HP, 380HP and 400HP, while 6×4 and 8×4 chassis configurations can be supplied according to mixer capacity and operating requirements. SINOTRUK lists WP10 engines at 300HP, 340HP and 380HP and WP12 engines at 400HP and 430HP for the HOWO-NX platform. Common HOWO NX mixer configurations cover approximately 8–12CBM effective mixing capacity. Representative 6×4 versions use 8–10CBM mixer bodies, while 8×4 and customized versions are available with larger mixer drums. The reinforced chassis, heavy-duty axles and high-strength subframe provide stable support for continuous loaded operation, while the hydraulic mixer system allows smooth adjustment of drum rotation direction and speed during loading, transportation and discharge.
- Tel+86 139 6411 3362
- WhatsApp+86 139 6411 3362
- Emailluisa@sdlvnengintel.com
Product Description
Product Specifications
| Item | Specification Range |
|---|---|
| Product Type | Concrete Mixer Truck / Cement Mixer Truck / Transit Mixer Truck |
| Brand | SINOTRUK HOWO |
| Model Series | HOWO NX |
| Drive Type | 6×4 / 8×4 available |
| Engine Power | 340HP / 380HP / 400HP available according to chassis and stock |
| Engine Brand | Weichai / SINOTRUK |
| Common Engine Series | WP10 / WP12 / MC11 series according to configuration |
| Common Engine Model | WP10.380E22 / WP12 series / MC11 series or equivalent |
| Engine Type | Six-cylinder, turbocharged and intercooled diesel engine |
| Engine Displacement | Approx. 9.7–11.6 L for common WP10 / WP12 configurations |
| Fuel Type | Diesel |
| Emission Standard | Euro II / Euro III / Euro V / Euro VI available according to model year and export market |
| Transmission Brand | SINOTRUK |
| Transmission Type | Manual transmission |
| Common Transmission | HW19710 / HW19712 or equivalent |
| Transmission Gears | 10-speed / 12-speed manual transmission available |
| PTO | Heavy-duty power take-off for mixer hydraulic system |
| Cab Series | HOWO NX |
| Common Cab | H77L / other NX cab configuration according to chassis |
| Cab Width | Approx. 2,495 mm |
| Seating Capacity | 2 persons commonly available |
| Sleeper | Single sleeper available |
| Driver Seat | Air-suspension / adjustable driver seat available |
| Cab Suspension | Four-point suspension available |
| Steering | Left-hand drive or right-hand drive optional |
| Power Steering | Hydraulic power steering |
| Air Conditioner | Available |
| Overall Length | Approx. 8,800–10,800 mm depending on chassis and mixer capacity |
| Overall Width | Approx. 2,500–2,550 mm |
| Overall Height | Approx. 3,700–4,000 mm |
| Wheelbase | Approx. 3,800 + 1,350 mm for common 6×4 configurations; different wheelbases available for 8×4 |
| Gross Vehicle Weight | Approx. 25–35 tons depending on chassis and mixer capacity |
| Curb Weight | Approx. 12–16 tons depending on chassis and upper body |
| Maximum Driving Speed | Approx. 80–100 km/h |
| Front Axle | VGD / V-series heavy-duty steering axle |
| Front Axle Capacity | Approx. 7.5–9.5 tons depending on chassis |
| Rear Axle | MC / MCX series heavy-duty drive axle |
| Rear Axle Capacity | Approx. 13–16 tons per drive axle depending on configuration |
| Rear Axle Type | Single-reduction / hub-reduction axle according to chassis |
| Differential Lock | Available |
| Frame | Reinforced high-strength steel ladder frame |
| Subframe | Reinforced mixer-truck subframe |
| Front Suspension | Multi-leaf spring suspension |
| Rear Suspension | Reinforced multi-leaf spring / bogie suspension |
| Tire Model | 12.00R20 / 315/80R22.5 or equivalent |
| Tire Quantity | According to 6×4 / 8×4 chassis; spare tire optional |
| Fuel Tank | Approx. 300–400 L |
| Fuel Tank Material | Aluminum / steel according to configuration |
| Brake System | Dual-circuit compressed-air brake system |
| Parking Brake | Spring-energy compressed-air brake |
| Auxiliary Brake | Engine exhaust brake available |
| ABS | Available |
| Electrical System | 24V |
| Effective Mixer Capacity | 8CBM / 9CBM / 10CBM / 12CBM available |
| Mixer Drum Type | Rotating concrete mixing drum |
| Mixer Drum Material | High-strength wear-resistant steel |
| Drum Structure | Reinforced drum with internal spiral mixing blades |
| Drum Rotation | Forward / reverse rotation |
| Drum Rotation Speed | Approx. 0–16 rpm depending on hydraulic system |
| Mixing Blade Type | Double-helical / spiral mixing blades |
| Blade Material | High-strength wear-resistant steel |
| Hydraulic Drive Type | Hydrostatic hydraulic mixer drive |
| Hydraulic Pump | PMP / EATON / equivalent heavy-duty hydraulic pump optional |
| Hydraulic Motor | PMP / EATON / equivalent hydraulic motor optional |
| Reducer | Bonfiglioli / PMP / equivalent mixer reducer optional |
| Hydraulic Oil Tank | Available |
| Hydraulic Oil Cooler | Available / optional |
| Feeding System | Rear feeding hopper |
| Feeding Hopper | Reinforced large-capacity feeding hopper |
| Hopper Material | High-strength steel with wear-resistant lining optional |
| Feeding Speed | Approx. ≥3 m³/min depending on configuration |
| Discharge System | Rear discharge chute |
| Discharge Speed | Approx. 2–3 m³/min depending on concrete condition and mixer configuration |
| Main Discharge Chute | Adjustable and rotatable discharge chute |
| Extension Chute | Extension chute available / optional |
| Concrete Residual Rate | Low-residual drum and blade design |
| Water Tank Capacity | Approx. 300–500 L |
| Water System | Pressurized / gravity water supply system |
| Drum Cleaning | Integrated water flushing system |
| Hopper Cleaning | Water cleaning system available |
| Chute Cleaning | Water cleaning system available |
| Hand-Washing Outlet | Optional |
| Rear Operating Control | Mechanical / electro-hydraulic control |
| Drum Speed Control | Adjustable |
| Drum Direction Control | Mixing / neutral / discharge |
| Cab Drum Control | Optional |
| Support Roller | Heavy-duty mixer drum support rollers |
| Drum Support | Reinforced front and rear drum support structure |
| Rear Ladder | Available |
| Rear Fender | Available |
| Reversing Camera | Optional |
| Rear Working Camera | Optional |
| Working Lights | Optional |
| Warning Lamp | Optional |
| Toolbox | Available / optional |
| Fire Extinguisher | Available / optional |
| Color | White, red, blue, green, yellow or customized |
| Condition | Used / Refurbished / Customized according to stock |
| Customization | Engine, transmission, drive type, mixer capacity, drum material, hydraulic pump, hydraulic motor, reducer, water system, axle, tires, steering side, paint color, company logo and export markings |
Product Details
Typical Applications
- Ready-mixed concrete transportation
- commercial concrete batching plants
- residential building construction
- commercial building construction
- industrial plant construction
- highway construction
- urban road construction
- bridge construction
- tunnel construction
- railway projects
- airport construction
- port construction
- municipal infrastructure
- hydropower projects
- industrial park development
- foundation construction
- mining infrastructure
- precast concrete projects
- large-scale infrastructure projects
- urban development
- construction contractor fleet operations.
Available Configurations
- 340HP, 380HP or 400HP diesel engine
- Weichai WP10, WP12 or SINOTRUK MC-series engine according to chassis
- 6×4 or 8×4 drive configuration
- left-hand drive or right-hand drive
- Euro II / Euro III / Euro V / Euro VI emission configuration according to model year and market
- HOWO NX H77L or other compatible NX cab
- HW19710, HW19712 or equivalent manual transmission
- 8CBM, 9CBM, 10CBM or 12CBM effective mixer capacity
- high-strength wear-resistant mixer drum
- reinforced spiral mixing blades
- PMP, EATON or equivalent hydraulic pump
- PMP, EATON or equivalent hydraulic motor
- Bonfiglioli, PMP or equivalent mixer reducer
- hydraulic oil cooling system
- approximately 300–500L water tank
- pressurized water system
- reinforced feeding hopper
- wear-resistant hopper lining
- adjustable discharge chute
- extension discharge chute
- mechanical or electro-hydraulic rear controls
- cab-mounted drum control
- rear working camera
- reversing camera
- working lights
- warning lamps
- ABS
- air conditioner
- air-suspension driver seat
- different axle and tire configurations
- spare tire
- toolbox
- fire extinguisher
- customized mixer capacity, hydraulic system, paint color, company logo and export markings.
Buyer Support
- HOWO NX Concrete Mixer Truck combines the cost-effective HOWO NX heavy-duty chassis with a professional concrete mixing and transportation system for ready-mixed concrete plants, contractors and infrastructure projects
- 340HP, 380HP and 400HP engine configurations provide strong power for loaded concrete transportation, construction-site access and continuous commercial operation
- 6×4 and 8×4 chassis configurations allow the vehicle to meet different mixer-capacity and axle-load requirements
- 8CBM, 9CBM, 10CBM and 12CBM mixer options cover a wide range of medium- and heavy-duty concrete transportation applications. The HOWO NX platform uses WP and MC-series diesel engines together with durable HW-series transmissions, providing multiple powertrain combinations for different operating conditions. High-strength mixer drums and reinforced spiral blades provide continuous concrete agitation during transportation and efficient feeding and discharge at the job site
- the hydrostatic hydraulic drive system provides smooth drum rotation and adjustable operating speed
- PMP, EATON, Bonfiglioli and equivalent hydraulic components can be selected according to project and stock requirements. The reinforced frame, heavy-duty drive axles, multi-leaf spring suspension and dedicated mixer subframe provide strong support for continuous loaded operation
- approximately 300–500L water-system options support cleaning of the mixer drum, feeding hopper and discharge chute after unloading
- adjustable rear discharge chutes simplify concrete placement at construction sites
- the HOWO NX cab provides a wider 2,495mm structure and comfort-oriented equipment including suspension seating and available four-point cab suspension. Left-hand-drive and right-hand-drive versions can be supplied for different export markets, while engine, transmission, drive configuration, mixer capacity, hydraulic components, water system, tires, paint color and other equipment can be customized.
