FAW Jiefang J6F 4×2 Dropside Cargo Truck 110 / 120 / 130HP Available
FAW Jiefang J6F 4×2 dropside cargo truck is a light-duty commercial vehicle designed for urban distribution, regional logistics, agricultural products, building materials and general cargo transportation. Its compact cab-over design provides good maneuverability and efficient chassis space utilization, making it suitable for city streets, wholesale markets, farms, warehouses and short-to-medium-distance delivery routes. The J6F light-truck platform is available with 110HP, 120HP and 130HP FAW diesel engines. FAW’s official J6F specifications include 3.0L diesel power, 4×2 chassis layouts and multiple gross vehicle weight configurations for different light-duty transport requirements. The open dropside cargo body allows convenient loading and unloading from the rear and both sides. Cargo-body length, side-panel height, wheelbase, transmission, tires, driving side, paint color and other configurations can be customized according to transportation requirements.
- Tel+86 139 6411 3362
- WhatsApp+86 139 6411 3362
- Emailluisa@sdlvnengintel.com
Product Description
Product Specifications
| Item | Specification Range |
|---|---|
| Product Type | Dropside Cargo Truck / Sidewall Cargo Truck / Light Duty Cargo Truck |
| Brand | FAW Jiefang |
| Model Series | J6F / CA1041 / CA1081 Series |
| Drive Type | 4×2 |
| Engine Power | 110HP / 120HP / 130HP available |
| Engine Brand | FAW / FAWDE |
| Engine Type | Four-cylinder turbocharged and intercooled diesel engine |
| Engine Displacement | Approx. 3.0 L |
| Fuel Injection | High-pressure common-rail fuel injection |
| Fuel Type | Diesel |
| Emission Standard | Euro IV / Euro V available; other export standards according to stock |
| Transmission | 5-speed / 6-speed manual transmission optional |
| Cab Type | Low cab-over single-row cab |
| Seating Capacity | 2–3 persons |
| Steering | Left-hand drive or right-hand drive optional |
| Overall Length | Approx. 5,960–7,000 mm, depending on wheelbase and cargo body |
| Overall Width | Approx. 1,850–2,300 mm |
| Overall Height | Approx. 2,250–2,700 mm |
| Wheelbase | Approx. 3,300–3,900 mm |
| Cargo Body Type | Open dropside / flatbed with side panels |
| Cargo Body Length | Approx. 3,800–5,200 mm |
| Cargo Body Width | Approx. 1,800–2,200 mm |
| Cargo Body Height | Approx. 350–600 mm |
| Cargo Body Material | High-strength steel |
| Side Panel Type | Foldable / removable side panels optional |
| Curb Weight | Approx. 2,250–3,500 kg, depending on chassis and body |
| Gross Vehicle Weight | Approx. 4.5–8 tons, depending on model and local regulations |
| Rated Payload | Approx. 2–5 tons, depending on chassis and certification |
| Front Axle Capacity | Approx. 2–3 tons |
| Rear Axle Capacity | Approx. 3.5–5 tons |
| Rear Axle Type | Single-reduction drive axle |
| Frame | Reinforced high-strength steel chassis |
| Front Suspension | Leaf spring suspension |
| Rear Suspension | Reinforced multi-leaf spring suspension |
| Tire Model | 6.50R16 / 7.00R16 / 7.50R16 optional |
| Tire Quantity | 6 tires + spare tire |
| Fuel Tank | Approx. 100–150 L, depending on configuration |
| Brake System | Hydraulic or compressed-air brake system according to chassis |
| Safety System | ABS available |
| Maximum Speed | Approx. 90–110 km/h, depending on engine and axle ratio |
| Air Conditioner | Optional |
| Power Steering | Available |
| Cargo Body Customization | Length, width, floor structure and side-panel height can be customized |
| Color | White, blue, red, green, silver or customized |
| Condition | Used / Refurbished / Customized according to stock |
| Customization | Engine, transmission, wheelbase, cargo body, tires, driving side, color, logo and accessories |
Product Details
Typical Applications
- Urban goods distribution
- intercity logistics
- agricultural product transportation
- fruit and vegetable transportation
- building material delivery
- hardware and machinery transportation
- supermarket delivery
- wholesale market transportation
- beverage and packaged food distribution
- furniture transportation
- household goods transportation
- farm supply delivery
- factory logistics
- express delivery
- general commercial cargo transportation.
Available Configurations
- 110HP, 120HP or 130HP diesel engine
- Euro IV or Euro V emission standard
- left-hand drive or right-hand drive
- 5-speed or 6-speed manual transmission
- different wheelbases
- approximately 3.8m, 4.2m, 4.8m or longer cargo body
- foldable or removable side panels
- reinforced steel cargo floor
- wooden or steel floor structure
- higher side panels
- tarpaulin frame
- toolbox
- rear ladder
- spare tire
- air conditioner
- power steering
- ABS
- customized cargo-body dimensions, paint color, company logo and export markings.
Buyer Support
- FAW Jiefang J6F 4×2 dropside cargo truck combines compact dimensions, practical payload capability and economical operating costs for daily commercial transportation
- 110–130HP engine options provide suitable power for urban and regional cargo delivery
- cab-over design improves maneuverability and allows more chassis length to be used for cargo
- the open dropside body allows cargo to be loaded and unloaded from the rear or either side
- different cargo-body lengths and side-panel heights can meet agricultural, building-material and general logistics requirements
- leaf-spring suspension provides durable support for frequent commercial operation
- the lightweight chassis helps improve payload efficiency and fuel economy
- simple mechanical construction makes daily maintenance and servicing convenient
- multiple configurations can be supplied for different export markets. FAW positions the J6F light-truck range around higher productivity, maneuverability and lower cost of ownership.
