Special Trucks
Dongfeng Truck Mounted Crane 140 / 170 / 190 / 210 / 240 / 260 / 290HP 3.2 / 5 / 6.3 / 8 / 10 / 12 / 14T Available
Dongfeng Truck Mounted Crane is a multipurpose lifting and transportation vehicle designed for construction, engineering projects, machinery handling, utility work, industrial equipment installation and material transportation. The vehicle combines a reliable Dongfeng commercial chassis with a hydraulic truck-mounted crane, reinforced crane subframe, hydraulic outriggers and cargo body, allowing lifting, loading, transportation and unloading to be completed by one truck. Dongfeng crane trucks are available with 4×2, 6×4 and 8×4 chassis configurations. Engine options include approximately 140HP, 170HP, 190HP, 210HP, 240HP, 260HP and 290HP, while crane capacities of approximately 3.2T, 5T, 6.3T, 8T, 10T, 12T and 14T can be selected according to chassis capacity, cargo payload and lifting requirements. Straight-boom cranes are suitable for general construction and cargo handling where longer working radius and greater lifting height are required. Knuckle-boom cranes can also be selected for projects requiring compact installation and flexible lifting in restricted spaces. Crane brand, boom sections, lifting capacity, working radius, outriggers, cargo-body dimensions and control system can be customized according to project requirements.
- Tel+86 139 6411 3362
- WhatsApp+86 139 6411 3362
- Emailluisa@sdlvnengintel.com
Product Description
Product Specifications
| Item | Specification Range |
|---|---|
| Product Type | Truck Mounted Crane / Crane Truck / Lorry Mounted Crane / Cargo Truck with Crane |
| Brand | Dongfeng |
| Chassis Brand | Dongfeng |
| Common Chassis Series | Duolika / Tianjin / Tianlong / KR or equivalent Dongfeng chassis |
| Drive Type | 4×2 / 6×4 / 8×4 available |
| Engine Power | 140HP / 170HP / 190HP / 210HP / 240HP / 260HP / 290HP available |
| Engine Brand | Dongfeng Cummins / Yuchai / Dongfeng or equivalent |
| Engine Type | Four-cylinder / six-cylinder turbocharged and intercooled diesel engine |
| Fuel Type | Diesel |
| Emission Standard | Euro III / Euro V / Euro VI available according to chassis and export market |
| Transmission Type | Manual transmission |
| Transmission Gears | 6-speed / 8-speed / 9-speed / 10-speed available according to chassis |
| PTO | Heavy-duty PTO for hydraulic crane system |
| Cab Type | Standard / extended Dongfeng cab according to chassis |
| Seating Capacity | 2–3 persons |
| Sleeper | Available on selected medium- and heavy-duty chassis |
| Driver Seat | Adjustable / air-suspension seat optional |
| Steering | Left-hand drive / right-hand drive optional |
| Power Steering | Available |
| Air Conditioner | Available / optional |
| Overall Length | Approx. 7,000–12,000 mm depending on chassis, crane and cargo body |
| Overall Width | Approx. 2,300–2,550 mm |
| Overall Height | Approx. 2,900–3,900 mm |
| Wheelbase | Multiple wheelbase configurations available |
| Gross Vehicle Weight | Approx. 12–41 tons depending on chassis |
| Curb Weight | Approx. 6–19 tons depending on crane and cargo body |
| Rated Payload | According to chassis, crane weight, cargo body and local certification |
| Maximum Driving Speed | Approx. 80–100 km/h |
| Front Axle | Dongfeng steering axle |
| Rear Axle | Dongfeng heavy-duty drive axle |
| Rear Axle Type | Single-reduction / hub-reduction available |
| Differential Lock | Available on selected heavy-duty configurations |
| Frame | Reinforced high-strength steel chassis frame |
| Crane Subframe | Heavy-duty reinforced crane mounting subframe |
| Front Suspension | Leaf spring suspension |
| Rear Suspension | Reinforced multi-leaf spring / balance suspension |
| Tire Model | 8.25R16 / 9.00R20 / 10.00R20 / 11.00R20 / 12.00R20 / 275/80R22.5 or equivalent |
| Tire Quantity | According to 4×2 / 6×4 / 8×4 chassis |
| Spare Tire | Available / optional |
| Fuel Tank | Approx. 150–400 L depending on chassis |
| Brake System | Hydraulic / dual-circuit compressed-air brake system according to chassis |
| Parking Brake | Mechanical / spring-energy compressed-air brake according to chassis |
| Auxiliary Brake | Engine exhaust brake available |
| ABS | Available |
| Electrical System | 24V |
| Crane Type | Straight Boom Crane / Knuckle Boom Crane optional |
| Crane Installation Position | Behind cab standard / rear-mounted optional |
| Crane Brand | XCMG / SANY / other compatible Chinese crane brands |
| Rated Crane Capacity | 3.2T / 5T / 6.3T / 8T / 10T / 12T / 14T available |
| Light Crane Capacity | Approx. 3.2–5 tons |
| Medium Crane Capacity | Approx. 6.3–8 tons |
| Heavy Crane Capacity | Approx. 10–14 tons |
| Boom Sections | 2 / 3 / 4 / 5 / 6 sections depending on crane model |
| Boom Structure | Hydraulic telescopic straight boom / articulated folding boom |
| Boom Material | High-strength structural steel |
| Maximum Lifting Height | Approx. 8–21 m depending on crane model |
| Maximum Working Radius | Approx. 7–19 m depending on crane model |
| Maximum Lifting Moment | According to crane model and rated lifting capacity |
| Boom Extension | Hydraulic telescopic |
| Boom Elevation | Hydraulic |
| Crane Slewing | Hydraulic rotation |
| Slewing Angle | 360° continuous / limited rotation depending on crane model |
| Slewing Bearing | Heavy-duty slewing bearing |
| Main Hook | Heavy-duty lifting hook |
| Hook Block | Single / multi-sheave according to crane |
| Steel Wire Rope | High-strength lifting wire rope |
| Main Winch | Hydraulic winch |
| Winch Brake | Automatic hydraulic / mechanical brake |
| Hydraulic Pump | PTO-driven hydraulic pump |
| Hydraulic Working Pressure | Approx. 20–32 MPa depending on crane |
| Hydraulic Oil Tank | Available |
| Hydraulic Oil Cooler | Optional |
| Hydraulic Control Valve | Multi-way proportional hydraulic valve |
| Hydraulic Cylinders | Heavy-duty hydraulic cylinders |
| Crane Control System | Manual hydraulic / electro-hydraulic control |
| Ground Control | Available |
| High-Seat Control | Optional |
| Wireless Remote Control | Optional |
| Cab-Mounted Control | Optional |
| Emergency Manual Control | Available / optional |
| Overload Protection | Available / optional |
| Moment Limiter | Optional |
| Load Indicator | Optional |
| Boom Angle Indicator | Optional |
| Outrigger Type | Hydraulic H-type / telescopic outriggers |
| Front Outriggers | Available |
| Rear Outriggers | Optional / recommended for larger cranes |
| Outrigger Extension | Manual / hydraulic optional |
| Outrigger Span | According to crane model |
| Vertical Outrigger Cylinder | Hydraulic |
| Outrigger Foot Pads | Heavy-duty steel pads |
| Cargo Body Type | Dropside cargo body / flatbed cargo body |
| Cargo Body Length | Approx. 4,500–8,500 mm depending on chassis and crane |
| Cargo Body Width | Approx. 2,300–2,500 mm |
| Cargo Body Height | Approx. 500–800 mm for dropside configuration |
| Cargo Body Material | Carbon steel / high-strength steel |
| Cargo Floor | Checkered steel plate / flat steel plate / wood-steel combination optional |
| Floor Thickness | Approx. 3–8 mm or customized |
| Side Wall Thickness | Approx. 2–4 mm or customized |
| Side Panels | Fixed / foldable / removable optional |
| Rear Tailgate | Foldable / removable |
| Cargo Body Reinforcement | Reinforced longitudinal and transverse beams |
| Flatbed Configuration | Optional |
| Dropside Configuration | Available |
| Stake Body Configuration | Optional |
| Rear-Mounted Crane Configuration | Optional |
| Hydraulic Rear Outriggers | Optional |
| Auxiliary Winch | Optional |
| Additional Hook | Optional |
| Working Basket | Optional for compatible crane applications |
| Lifting Slings | Optional |
| Shackles | Optional |
| Spreader Beam | Optional |
| Crane Working Lights | Optional |
| Boom Working Light | Optional |
| Reversing Camera | Optional |
| Crane Camera | Optional |
| 360° Monitoring System | Optional |
| LED Warning Lights | Optional |
| Audible Warning Alarm | Optional |
| Toolbox | Available |
| Outrigger Pad Storage | Available / optional |
| Fire Extinguisher | Available / optional |
| Color | White, red, blue, yellow, orange, green or customized |
| Condition | Used / Refurbished / Customized according to stock |
| Customization | Chassis series, engine, drive type, crane brand, crane capacity, boom sections, lifting height, working radius, outriggers, cargo body size, hydraulic system, control system, steering side, cameras, paint color, company logo and export markings |
Product Details
Typical Applications
- Construction-material lifting and transportation
- steel transportation
- prefabricated component lifting
- machinery loading and unloading
- generator transportation
- transformer installation
- electrical equipment handling
- utility construction
- power-line projects
- telecommunications projects
- pipeline construction
- road construction
- bridge construction
- building-material delivery
- industrial equipment installation
- factory equipment relocation
- warehouse cargo handling
- port and terminal operations
- municipal engineering
- mining-site material handling
- agricultural machinery transportation
- landscaping projects
- emergency lifting operations.
Available Configurations
- 140HP, 170HP, 190HP, 210HP, 240HP, 260HP or 290HP diesel engine
- Dongfeng 4×2, 6×4 or 8×4 chassis
- Dongfeng Cummins, Yuchai or equivalent diesel engine
- left-hand drive or right-hand drive
- Euro III / Euro V / Euro VI configuration according to chassis
- 6-speed, 8-speed, 9-speed or 10-speed manual transmission
- 3.2T, 5T, 6.3T, 8T, 10T, 12T or 14T truck-mounted crane
- XCMG, SANY or other compatible crane brands
- straight-boom or knuckle-boom crane
- 2-section, 3-section, 4-section, 5-section or 6-section boom
- approximately 8–21m maximum lifting height
- approximately 7–19m maximum working radius
- 360° rotation according to crane model
- hydraulic H-type outriggers
- optional rear hydraulic outriggers
- ground control
- high-seat control
- electro-hydraulic proportional control
- wireless remote control
- overload protection
- moment limiter
- load indicator
- approximately 4.5–8.5m cargo body
- dropside cargo body
- flatbed cargo body
- removable side panels
- reinforced steel floor
- rear-mounted crane configuration
- auxiliary winch
- working basket
- lifting slings
- shackles
- crane camera
- reversing camera
- 360° monitoring system
- LED working lights
- toolbox
- customized crane capacity, cargo body dimensions, paint color, company logo and export markings.
Buyer Support
- Dongfeng Truck Mounted Crane combines a reliable Dongfeng commercial chassis with a professional hydraulic crane and cargo body, allowing one vehicle to complete lifting, loading, transportation and unloading operations. This integrated configuration reduces dependence on separate cranes and transport trucks and improves efficiency for construction, engineering, municipal and industrial projects. Crane capacities from approximately 3.2T to 14T cover a wide range of lifting requirements. 3.2T and 5T cranes are suitable for building materials, utility equipment and light machinery
- 6.3T and 8T cranes provide greater lifting capacity for general engineering applications
- 10T, 12T and 14T configurations are suitable for heavier machinery, industrial equipment and construction materials. 4×2, 6×4 and 8×4 chassis configurations allow different combinations of crane size, cargo payload and operating stability. 4×2 versions provide good maneuverability for urban construction and municipal work, while 6×4 and 8×4 chassis provide greater load capacity and support for larger cranes and heavier cargo. Straight-boom cranes provide longer lifting height and working radius for general cargo handling and construction applications. Knuckle-boom cranes can be selected for customers requiring compact folded dimensions and flexible lifting around buildings, equipment or restricted work areas. Hydraulic outriggers provide stable support during lifting. Larger crane configurations can be equipped with additional rear outriggers to increase the support area and improve stability when operating at longer boom extensions. Ground controls, high-seat controls and optional wireless remote control provide flexible operating methods. Overload protection, moment limiters, load indicators and optional monitoring cameras can be selected to improve working control and safety. The reinforced cargo body allows materials and machinery to be transported immediately after loading. Cargo-body dimensions, side-wall height, floor thickness and structure can be customized according to steel, construction materials, generators, machinery and industrial equipment. Left-hand-drive and right-hand-drive versions are available for different export markets. Chassis series, engine power, crane brand, lifting capacity, boom sections, working radius, lifting height, outriggers, cargo-body dimensions, hydraulic controls, cameras, paint color and other specifications can be customized according to project requirements.
Product Display
